High Quality Auto Wheel Hub Unit 513011
US$ 10 - 25
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Material:
Steel
Finishing:
Bright
Brand Name:
CIE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Free Sample Auto 513074 Steel Wheel Hub Unit BearingUS$ 10 - 25MOQ: 500 Pieces -
High Quality Hub Unit (513061)US$ 15 - 30MOQ: 500 Pieces
-
High Quality Wheel Hub Unit DACF1083CR-1US$ 10 - 25MOQ: 500 Pieces
-
High Quality Wheel Hub Units 578413US$ 10 - 25MOQ: 500 Pieces
-
High Quality Wheel Unit 52710-29450US$ 10 - 25MOQ: 500 Pieces
Material
Steel
Finishing
Bright
Brand Name
CIE
Place of Origin
Zhejiang, China
Model Number
513011
Specifications
auto wheel hub unit 513011:More than 100 different types of 3nd general hub units are suitable for Japanese, Korean, Americauto wheel hub unit 513011 Features:
1.material:
1) Chrome steel.Steel from the Fifth Factory Of Shanghai Steel Company
2) Lubrication grease from ESSO and Shell
3) Nylon of the keeping shelf from DuPont
2.quality certification:ISO9001:2000 system
3.fields used in: series of cars,such as Fiat,Renault,Citroen,Fiat,BMW,Benz,Ford,Nissan, Opel and ect.
4.service:prompt delivery,OEM available
5.Advantage:competitive prices with excellent quality
3nd generation hub units
| Hub Unit | Dimension(mm) | Inner Flange | |||||||||
| General No. | A | B | C | D | E | F | G | Hole Size | Bolt Size | ||
| H | I | J | |||||||||
| 100104 | 116.8 | 98 | 58.9 | 57.9 | - | 52 | 85 | 4XM12X1.25 | - | 4XΦ10X1.25 | 20 |
| 513017 | 125.4 | 100 | 58.32 | 57.02 | 73.4 | 44.3 | 98.5 | - | 5XM12X1.5 | 3XΦ12.7 | 33 |
| 513016K | 146 | 115 | 70.63 | 70.15 | 90 | 41.78 | 116 | - | 5XM12X1.5 | 3XΦ12.7 | 27 |
| 513084 | 154 | 114.3 | 72 | 71.4 | 100 | 54 | 120.65 | - | 5X1/2-20UNF | 3XM12X1.75 | 27 |
| 52730-37102 | 148 | 114.3 | 75.9 | 66.9 | 65.9 | 59 | 100 | - | 4XM12X1.5 | 4XM10X1.25 | - |
| 513074 | 139 | 114.3 | 72.8 | 71.2 | 86.8 | 37.7 | 112 | - | 5XM12X1.5 | 4XM10X1.5 | 26 |
| 513075 | 126 | 100 | 60.7 | 56.7 | 87 | 37.3 | 112 | - | 5XM12X1.5 | 4XM10X1.5 | 26 |
| 513011K | 125.4 | 100 | 57.73 | 57.02 | 71 | 41.96 | 102 | - | 5XM12X1.5 | 3XΦ13 | 33 |
| 574566B | 135.5 | 108 | 68 | 65 | 83.5 | 43 | 103 | 4XM12X1.75 | - | 4XM12X1.75 | 26 |
| BARB243823AD | 130.5 | 108 | 68 | 65 | 81 | 37 | 103 | 4XM14X1.5 | - | 4XM12X1.5 | 26 |
| 633293 | 116.8 | 98 | 58.9 | 57.9 | - | 52 | 85 | 4XM12X1.25 | - | 4XΦ10X1.25 | - |
| 513100 | 139 | 108 | 70.92 | 63.1 | 85.4 | 36.2 | 112 | - | 5XM12X1.5 | 3XM12X1.75 | 26 |
| 513087 | 145.5 | 115 | 70.61 | 70.1 | - | 42 | 116 | - | 5XM12X1.5 | 3XΦ14 | 33 |
| 513138 | 128 | 100 | 60.9 | 56.9 | 87 | 37.6 | 112 | - | 5XM12X1.5 | 3XM12X1.75 | 26 |
| 513122 | 126 | 100 | 56.8 | 60.8 | 87 | 37.5 | 112 | - | 5XM12X1.5 | 4XM10X1.5 | 26 |
| 513044 | 144.5 | 115 | 70.61 | 70.1 | 91.1 | 44.85 | 146.05 | - | 5XM12X1.5 | 4XM12X1.5 | 33 |
| 513089 | 146 | 114.3 | 73.3 | 71.4 | 91.3 | 42.1 | 116 | - | 5XM12X1.5 | 3XM12X1.75 | 33 |
| 513061 | 144.5 | 120.65 | 70.63 | 71.14 | 92 | 47.24 | 120.65 | - | 5XM12X1.5 | 3XM12X1.75 | 27 |
| 30BWK16 | 151.8 | 114.3 | 62 | 60 | - | 75 | 99 | 5XM12X1.5 | - | 4XΦ10.5 | - |
| 3DACF026-1 | 135 | 100 | 54.95 | 53.92 | 73.9 | 54.5 | - | - | 4XM10X1.25 | 4XM12X1.5 | - |
| 801106 | 139 | 120 | 79 | 74 | 90 | 51.1 | 106 | 5XM12X1.5 | - | 4XM12X1.5 | - |
| 42450-02090 | 135 | 100 | 54.95 | 53.92 | 73.9 | 54.5 | 93 | - | 4XM10X1.25 | 4XM12X1.5 | - |
| 42460-48010 | 152 | 114.3 | 62 | 60 | 74 | 74.5 | 99 | - | 5XM12X1.5 | 4XM12X1.5 | - |
| 9173872 | 135.6 | 108 | 67.9 | 65 | 87.5 | 59 | 112 | 5XM14X1.5 | - | 4X12X1.75 | - |
| 274298 | 135.6 | 108 | 67.9 | 65 | 87.5 | 59 | 112 | 5XM14X1.5 | - | 4XM12X1.75 | 36 |
| 89411-B2010 | - | 100 | 55 | 54 | 56 | 52.5 | 81.8 | - | 4XM12X1.5 | 4XΦ12.5 | - |
| 3DACF026-2 | 135 | 100 | 54.95 | 53.92 | 73.9 | 54.5 | - | - | 4XM12X1.5 | 4XM12X1.25 | - |
| 513124 | 145.5 | 120.65 | 70.62 | 70.14 | 91.9 | 47 | 120.65 | - | 5XM12X1.5 | 3XM12X1.75 | 27 |
| 513159 | 164 | 114.3 | 71.8 | 71.4 | 100 | 54 | 120.65 | - | 5X1/2-20UNF | 3XM12X1.75 | 27 |
| 513123 | 139.3 | 114.3 | 73.25 | 71.32 | 87 | 37.5 | 112 | - | 5XM12X1.5 | 4XM10X1.5 | 26 |
| 513122 | 126 | 100 | 56.8 | 60.8 | 87 | 37.5 | 112 | - | 5XM12X1.5 | 4XM10X1.5 | 26 |
| 512155 | 126.3 | 100 | 56.84 | 57.34 | 86 | 48 | 108 | - | 5XM12X1.5 | 4XM12X1.5 | - |
| 512001 | 138 | 100 | 57.5 | 57 | 61 | 65 | 88.7 | - | 5XM12X1.5 | 4XΦ11 | - |
| 513137 | 145 | 115 | 70.1 | 70.6 | - | 37.2 | 116 | - | 5XM12X1.5 | 3XM12X1.75 | 30 |
| 513156 | 140.3 | 114.3 | 71.8 | 71.3 | 86 | 48 | 108 | - | 5XM12X1.5 | 4XM12X1.5 | - |
| 513157 | 142.8 | 114.3 | 67 | 57 | 84 | 40.5 | - | - | 4XM12X1.5 | 4XM12X1.25 | 25 |
| 513158 | 153.5 | 114.3 | 72 | 71.4 | 100 | 48.3 | 120.65 | - | 5X1/2-20UNF | 3XM12X1.75 | 27 |
