Automatic Food PE Film Shrink Wrapping Packaging Machines
1. Instruction
1.1 Invert speed control.
1.2 Bottle entering→ Auto unscrambling bottle→ Pushing bottle→ Heat sealing-Cool cutting →Pressing PE→ Shrink→ Cooling.
1.3 This machine applies air-stirring mechanism in pushing bottle and hot sealing-cool cutting. (It uses flat silk pulse seal, the saw tooth knife cuts, the unique heat seal-cool cut mechanism, has guaranteed the packing agglutination, reliable, and artistic.)
1.4 Automatic unscrambling bottle’s appliance makes bottle changing more quickly and conveniently.
1.5 Delivering film mechanism and the tensity voluntarily adjust.
1.6 PLC programmable procedure control system.
1.7 Double air blowers, guaranteeing the temperature balance in the shrink stove with PAD temperature controller, which apparently saves energy.
1.8 It applies wing shape stainless steel heating system, which is durable for long time use.
1.9 The heatproof Bolivian filament special fluorine dragon transportation net belt is used in shrink part to ensure the steady of transportation and high strengthen wear proof.
1.10 This machine applies invert speed control net belt conveying mechanism.
1.11 The height of the conveyer shall be made towards client’s demand, and usually adjusting scope is 800±30mm
1.12 The direction of bottle entering can be adjusted according to client’s demand.
Automatic Food PE Film Shrink Wrapping Packaging Machines
2. Parameter
2.1 Max package dimension: L420×W278×H390mm
2.2 Min package dimension: L210×W140×H100mm
2.3 Material of shrink film: PE,PVC
2.4 Thickness of shrink film: 0.03—0.15mm (special demand shall be proposed for special making)
2.5 Thermal shrink temperature: it can be adjusted freely under 260°C.
2.6 Max capacity: 1-10bags/min (4×6) (3×4) (2×3) (2×2)
2.7 Total heating power: 18KW
2.8 Actual power: 15kw/h
2.9 Suitable voltage: 380/220V
2.10 Dimension:
2.11 Working air pressure 0.6-0.8Mpa,air consumption capacity: 0.3m3/min.
2.12 Gross weight: 1200KG
Automatic Food PE Film Shrink Wrapping Packaging Machines
3. Basic disposition
3.1 Canada TOUCHWIN 4.6 inches touch screen, and PLC control system.
3.2 Taiwan Aritac air-stirring device.
3.3 Inverter made in Taiwan China.
3.4 Stainless steel wing shape heating pipe, 12 pieces with1.5kw per one.
3.5 Sino-America Bolivian filament special fluorine dragon transportation net belt
3.6 AUTONICS light electricity switch.
3.7 The main material of the equipment is carbonic steel; some parts are made of stainless steel.
3.8 Outside pack: Plastic film and wooden case.
