High Quality CW61125B*1500B Common ;lathe Machine From Haishu Machine

Name: High Quality CW61125B*1500B Common ;lathe Machine From Haishu Machine
Brand: Haishu
SKU: 128496545
Availability: InStock

US$ 5,000 - 9,500 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Taian Haishu Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 1250

Place of Origin Shandong, China

Brand Name Haishu

Model Number CW61125B

Voltage 380v 50hz

Power(W) 22kw

Dimension(L*W*H) 4600*2150*1825

Weight 6000

Certification CE

After-sales Service Provided Overseas third-party support available

CW Series: CW61125B×1500B

Project	Unit	Technical parameters
Workpiece swing diameter over bed	mm	φ1250
The maximum length of the workpiece	mm	1500
Maximum turning diameter of the workpiece on the turret	mm	φ865
Rail width	mm	755
Spindle hole diameter	mm	130
The front taper spindle hole	mm	Metric systemφ140
Species spindle speed, range		Forward 21 kinds,2-200rpm
Spindle speed reverse species	species	Reverse 12 kinds,24-178 rpm
Every aspect of the spindle turret rotation species to feed rate	species	56
Longitudinal	mm/r	0.1-12
Lateral	mm/r	0.05-6
On the turret	mm/r	0.025-3
Effective species metric thread range		43 kinds 1-120mm
Effective species inch thread, range		29,28-3/8 Teeth / inch
Effective modulus thread species, range		45, 0.5-60mm
Pitch Thread valid species, range		25, 1-56mm
Turret maximum lateral travel	mm	630
Maximum stroke on the turret	mm	300
Fast moving speed vertical turret	mm/min	3470
Turret fast moving speed transverse	mm/min	1870
On the turret	mm/min	935
Tool-sectional dimensions	mm	45×45
Tailstock sleeve diameter	mm	160
Tailstock quill stroke	mm	300
Tailstock taper		Morse No.6
Main motor power	kw	22
Skate fast motor	kw	1.5
Overall dimensions )(L × W × H)	mm	4600×2150×1825
Maximum load	kg	6000
