2014 Hot Sale Made-in- China Economical Ultrasonic Flowmeter

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Model Number:

XY-UFM01

Xian Yuanshun Electrical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XI'AN

Delivery Detail:

Delivery time depends on order quantity.

Brand Name YS

Model Number XY-UFM01

Specifications

Made in China Good Price Clamp Ultrasonic Hydrogen Flowmeter

Features:

1.can be used as a non-contact measurement, installation directly without flow cut.

So apply to determined assessment the condition of network flow. Easy installation,low coast and does not influence the nominal production.

2.Have no additional pressure loss. Measuring of non-conductive liquid, its the supplement to Electromagnetic

flowmeter.

3.This flowmeter is application to large round pipe and rectangular pipe, and then in principle it is not restricted by

pipe diameter.

4.With video menu type interface, easy to operation and more powerful.

5.Record function.

6.High precision and more convenient.

7.Strong anti-interference.

8.Bi-directional measurement, can measure the positive and negative, the net cumulative flow,

9.Automatic memory before 64 days prior 64 months, the first 5 years of light product flow rate,

10.Automatic memory 64 days before the working status of flow meter,

11.Auto memory the former 64 times more time and power flows can be manual or automatic inspection in order to

reduce the flow losses,

12.Programmable volume (quantitative) Controller,

13. Configure GPRS / GSM module enables remote monitoring and control.

Specifications:

Measuring Principle	Ultrasonic wave transmission time difference principle, dual CPU working in parallel, 4-byte floating-point operations
Accuracy	Better than ±1.0 %
Repeatability	0.2%
Velocity	0.03-±32 m/s
Measurement Period	0.5S
Display	backlit LCD can display 2x20 letters instantaneous flow, cumulative flow, velocity, time, calories and other data signal output at the same time etc.
Keypad	4x4-key membrane keypad with tactile feedback
Input	Can input two current signals(such as: temperature, pressure, liquid level, etc. signals) in order to achieve heat measurements or a dual-purpose machine
Output	electric current signal 4-20mA or 0-20mA, etc. Impedance 0 - 1K, accuracy 0.1%
Isolated OCT output	for frequency output (0-9,999Hz)
Internal Alarm (Buzzer)	user programmable
External Alarm Driver	alarm signal can be transmitted to Relay or OCT output terminals to drive an external alarm.
Data Interface	RS-232 serial port.
Power	AC: 220VDC: 8~36VDC or AC7-30V
Power Consumption	< 2W
Work time	Continuous
Environment Temperature	-30-80 Degrees Celsius
Environment Humidity	85% RH
