Project |
Project Names |
Technical parameters |
Technical Specifications |
Maximum turning diameter over bed (mm) |
φ360/φ400 |
The largest diameter of workpiece rotation skateboard (mm) |
φ245 |
|
Max length of the (mm) |
750,1000 |
|
The main drive |
The main drive in the form |
Independent of the spindle, stepless frequency conversion |
Number of spindle speeds |
No class |
|
Spindle speed range (r/min) |
200-2500 |
|
Form the spindle head |
6Num,A2Style |
|
Diameter of Spindle Bore (mm) |
φ60 |
|
Front spindle taper hole |
MT6 |
|
Chuck diameter (mm) |
φ200/φ250 |
|
Power of main motor (KW) |
5.5 |
|
Feed system |
Knife stroke (mm) |
XTo:260 ZTo:750 |
Rapid traverse to the (mm/min) |
XTo:6000 ZTo:8000 |
|
Repeatability (mm) |
XTo:0.01 ZTo:0.015 |
|
Workpiece machining accuracy |
IT6-IT7 |
|
The surface roughness |
Ra1.6 |
|
Tailstock unit |
Diameter of tailstock quill (mm) |
φ60 |
Tailstock sleeve travel (mm) |
120 |
|
Tailstock sleeve taper taper |
MT4 |
|
Knife unit |
Standard |
Vertical Four-electric turret |
Special configuration options |
Horizontal six, eight-station electric knife or knife row |
|
Repeatability (mm) |
0.008 |
|
Arbor section (mm) |
20×20/25×25 |
|
Dimensions and weight |
Overall dimensions (L × W × H) (mm) |
2150*1450*1650,2400*1450*1650 |
Net weight (Kg) |
1800,2000 |
CK6136A CNC lathe
Second, the characteristics
1, Horizontal flat bed structure;
2, Spindle frequency stepless speed regulation;
3, X / Z axis servo-driven feed system;
4, Spindle bore increase (φ60mm); (Note: General spindle bore φ52mm)
5, Bed rail ultra-quenching;
6, Bed rails with side saddle and slide a "laminating" process;
7, Precision ball screws, high rigidity precision compound bearing structure;
8, Ball screw and guide rail with automatic lubrication surface;
9, There are vertical four-station turret, six-position, horizontal six-station eight-station and other options;
10,Required configuration manual, pneumatic, hydraulic or manual chuck, pneumatic, hydraulic tailstock.
11,CNC control system Guangzhou, Beijing KND, Guangtai CNC, Siemens, FANUC and other options.
Third, the use of
Suitable for steel, cast iron, nonferrous metals and other materials, semi-finishing and precision machining.
