Product Details

Place of Origin:

Shaanxi, China

Brand Name:

Model Number:

Y63

Product Description

Product introduction:

Gas monitoring device for SF6 gas insulated equipment,sf6 manoneter

widely used in high pressure switch electricity and electrical appliances industry.,whose main sensing element is spring tube and bimetallic strip. We’ve learnt advanced technology from the domestic and foreign counterparts,and so the product is certainly with a unique advanced temperature compensation function. This product test and control the high pressure switch and the SF6 gas density in the electrical equipment, ensure the normal operation of the equipment,and prevent sf6 gas from leaking and damaging the equipment and then it can easily protect the equipment.

paremeter:

range	-0.1—0.9Mpa
Accuracy class	grade 1 when 20℃±1℃,grade 1.5 when -40℃--20℃--60℃
Dimension	the diagram below shows the concept
thread	can supply goods according to customers requirements>
Conditions of usage	temperature:-40-60℃Atmospheric pressure: 86-106Kpa.relative humidity:≤95% RH>
Dielectric strength	AC2800V/1min 50HZ
Insulation electric resistance:	>500M
Anti-seismic property	20m/ s2
Protection class	IP65
Shock resistance	30g
Yearly gas leakage rate	<10-15Mpa,m³/s.
Contact capacity	30VA
Maximum working voltage	AC380V

advantage:

1.we can produce acoording to your requirments,OEM,ODM

2.we can supply ex-factory price as manufacturer,to help you defeat your opponent.

3.after payment we can deliver to you soon

4.we have ISO9001 certification and patent certification

feature:

1.Gas monitoring device for SF6 gas insulated equipment,sf6 manoneter
2.stainless steel
3.good sealing

YOU CAN CHOOSE ANY TRANSPOTATION WAY
