HB1514 WATERPROOF INSULATION TAPE
Applications:
Designed to insulate,moisture-seal and pad all connections up to 1000 volts.Suitable for different cable termination and joints.
Features:
l Double layer,it's rubber based insulating compounds laminated to a flexible,all weather grade vinyl(PVC) backing.
l Easily installed to provide maximum protection.
l Compatible with all common solid dielectric cable insulation.
l Service temperature: -20℃to 90℃
l Overload temperature: 100℃max
Technical properties:
Property |
Testing method |
Typical data |
Tensile strength |
GB/T 528-92 |
≥3.5MPa |
Elongation at break |
GB/T 528-92 |
≥200% |
Dielectric strength |
|
≥18kV/mm |
Dielectric constant |
GB/T 1693-81 |
3 |
Volume resistance |
GB/T 1692-92 |
≥1.0x1014Ω•cm |
Adhesive and self-amalgamation |
- |
Good |
Oxygen resistance |
- |
PASS |
Heat shock (105℃) |
- |
PASS |
Dimensions:
Code |
Thickness(mm) |
Width(mm) |
Length(mm) |
Standard packing |
HB1514 |
0.8 |
36 |
6000 |
50reels/carton |
*Other sizes and packing are available on requested.
Related information:
The product is supplied as rolls of specified dimensions. Recommend to store in the original packing, protected from moisture, dust, heat and sunlight.
