Home > Products > Insulating and splicing > Waterproof Insulation Electrical Tape Black Power Cable Protecting Tape
Waterproof Insulation Electrical Tape Black Power Cable Protecting Tape
- Dalian Port
- T/T
You May Like
Product Details
| Brand Name | CASAC | Model Number | HB1504 |
Product Description
HB1504 Complex waterproof insulation tape
Applications:
Primary electrical insulation for cable and wire connections rated up to 20kV, one layer is to be made of rubber and the other layer is mastic.Primary electrical insulation and protecting joints of communication stations.Moisture seal for cable and wire connections.Jacket seal on power cable application.
Features:
l Conformable for application over irregular surfaces.
l Compatible with solid dielectric cable insulations.
l Self-fusing tape
l Excellent weather and moisture resistance.
l Excellent adhesive and sealing characteristics with copper, aluminium and power cable jacket materials.
l Service temperature: -20℃to 90℃
l Overload temperature: 130℃max
Technical properties:
Property | Testing method | Typical data |
Tensile strength | GB/T 528-92 | ≥2.0MPa |
Elongation at break | GB/T 528-92 | ≥1000% |
Dielectric strength | GB/T 1695-81 | ≥20kV/mm |
Dielectric constant | GB/T 1693-81 | 2-3 |
Volume resistance | GB/T 1692-92 | ≥1x1014Ω•cm |
Adhesive and self-amalgamation | - | Good |
Oxygen resistance | - | PASS |
Heat shock (105℃) | - | PASS |
Dimensions:
Code | Thickness(mm) | Width(mm) | Length(mm) | Standard packing |
HB1504 | 1.8 | 50 | 3000 | 50reels/carton |
*Other sizes and packing are available on requested.
Related information:
The product is supplied as rolls of specified dimensions . Recommend to store in the original packing, protected from moisture, dust, heat and sunlight.
