Help CenterHigh Quality M30 EPDM Gasketed Dairy Plate Heat Exchanger
Related Products
-
China Liquid Cooler Stainless Steel Liquid Liquid Heat ExchangerUS$ 1,000 - 10,000MOQ: 1 Set -
M10 Gasketed Heat Exchanger for LiquidUS$ 100 - 1,000MOQ: 1 Set
-
Gasketed Plate Heat ExchangerUS$ 100 - 1,000MOQ: 1 Set
-
30 Gasketed Evaporator Plate Heat ExchangerUS$ 100 - 1,000MOQ: 1 Set
-
M6B Gasketed Plate Heat ExchangerUS$ 1,000 - 10,000MOQ: 1 Set
Specifications
1.gasket,plate,heat exchanger2.over 10 years experience
3.one year warrenty
4.food industry
High quality M30 EPDM gasketed dairy plate heat exchanger
Each plate is provided with a gasket, which seals the flow gaps to atmosphere and the media from one another. The plate package is mounted in a rack consisting of a fixed number of plates. Two pressure plates clamp this package together with tie rods. Single pass and multi-pass arrangements are standard with a surface area of up 1500m2 in one unit. Pure counter flow is employed to achieve maximum possible heat transfer.
Plate material
Stainless steel suitable for clean water, river water, edible oil, and mineral oil
Titanium and titanium palladium suitable for sea water, salt water, salt.
Hastelloy suitable for sulfuric acid, hydrochloric acid, phosphoric acid
Applications :
1,Chemical Industry. Alkaline Liquid Cooling; Acid Liquid Cooling; Manufacturing Processing Cooling; Water Circulation Cooling; Kerosene Oil Cooling; Salt Solution Cooling; Ethanol Cooling
2, Steel Industry: Mould Cooling; Boiler Water Cooling; Emulsion Cooling; Conticaster Cooling; Hydraulic Oil Cooling; Ammonia Cooling; Coke-oven Plant Water Cooling; Machinery Coolant Cooling.
3, Paper Industry Waste Water Cooling; Washing Water Cooling; Waste Water Evaporation; Heating Recovery System; Wood Pulp Condensation
4, Food & Beverage Juice Concentration; Syrup Heating; Extracting Water Heating; Original Juice Heating; Concentrated Juice Heating; Syrup Heating; Diluted Juice Heating; Juice with Carbonic Acid Gas Heating
5, Oil & Gas Industry Crude Oil Heating; Crude Oil Cooling; Oil Well Injection Water Heating
6, HVAC District Heating; District Cooling; Domestic Hot Water; Air Conditioner Cooling; Refrigeration; Ventilation; Vaporizer; Condenser 7, Marine Industry Central Heating and Cooling, Fresh Water generating etc.
The Specification type of plate heat exchanger
Main technical data of heat exchanger
No. |
ASSY Area m² |
No.of plate |
The max. testing pressure Mpa |
Dimension mm |
Theoretical weight(kg) |
||
L |
W |
H |
|||||
1 |
100 |
53 |
1.6 |
960 |
1150 |
2602 |
3780 |
2 |
200 |
105 |
1.6 |
1160 |
1150 |
2602 |
4350 |
3 |
300 |
158 |
1.6 |
1460 |
1150 |
2602 |
4940 |
4 |
400 |
211 |
1.6 |
1760 |
1150 |
2602 |
5520 |
5 |
500 |
263 |
1.6 |
2160 |
1150 |
2602 |
6100 |
6 |
600 |
316 |
1.6 |
2560 |
1150 |
2602 |
6800 |
Configuration diagram of plate heat exchanger
The characteristics of plate heat exchanger
1.The structure of plate heat exchanger is more compact compared with other heat exchangers.
2.Heat transfer under differential temperature of 1 °C temperature with designed pressure up to 2.5MPa and the maximum handling capacity up to 3533m3 per hour is available.
3.Rich plate shape, a variety of angles and groove depth and a different combination forms a ideal heat exchanger which is suitable for working conditions.
4.One step forming plate with high-precision mold to reduce physical stress & improve plate’s uniformity and extend service life .
5.Reasonable flow guide plate designed to avoid the deposit plate and improve the heat transmission coefficient up to 9000W per m2.K.
6.Different material such as Stainless steel , titanium, Hastelloy, or other special alloy plate are available to meet the requirements of various working conditions.
7.Plate is easy to inspect and to manually clean. It can be cleaned by counter-current
washing in many cases. Daily cleaning of the plate is not time consuming and does not need the professionals.
8.Free paste type to reduce operation and maintenance costs, easy maintenance.
9.The heat exchange can be designed in many types from two fluid media with single countercurrent to three or more fluid media with multi current, through the changing of flow type or increasing the flow passage. Therefore more suitable solutions can be selected by designers to meet different technical requirements.
10.Economy, Its high heat transfer coefficient, easy installation and maintenance make the initial investment and operation and maintenance costs greatly reduced.
Pls contact us as following:
Helen Export manager
Liaoning Success Thermal Technology Co., LTD
ADD: Xiliu Industry Park, Haicheng City, Liaoning Provience, China
TEL: 0086-412-3814777FAX: 0086-412-3235096
Mobile: 0086-138 897 03395
SKYPE: successhelen1
