Home > Manufacturing & Processing Machinery > Lifting Equipment > Stacker & Reclaimer > 1500kg Economy Mini Pallet Truck CBD15C
1500kg Economy Mini Pallet Truck CBD15C
US$ 1,000 - 3,000
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
YI-LIFT
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2000kg AC Control Strong Electric Pallet Truck CBD20-410US$ 2,000 - 6,000MOQ: 2 Pieces -
2000kg Stand on Electric Pallet Truck 2000kg CBD20-490US$ 2,000 - 8,000MOQ: 2 Pieces
-
3T Electric Pallet Truck Side Way Battery EPS AC Control CBD30-460US$ 2,000 - 6,000MOQ: 2 Pieces
-
Semi Electric Stacker Wide View CDD10-080US$ 1,000 - 2,000MOQ: 2 Pieces
-
Hand Stacker PZUS$ 100 - 500MOQ: 2 Pieces
Condition
New
Place of Origin
Jiangsu, China
Brand Name
YI-LIFT
Model Number
CBD15C
Dimension(L*W*H)
1730*710*1320
Certification
ISO9001
Warranty
1 Year
After-sales Service Provided
No overseas service provided
1500kg economy mini pallet truck CBD15C
| Model | CBD15C | |
| Power type | Battery | |
| Driving style | Pedestrian | |
| Load capscity Q | Kg | 1500 |
| Load center C | mm | 600 |
| Overall lenth L1 | mm | 1730 |
| Overall width W | mm | 710 |
| Overall height H1 | mm | 1320 |
| Fork dimension L×b×m | mm | 1150×160×50 |
| Out width of forks D | mm | 540,680 |
| Base clearance x | mm | 30 |
| Base distance L0 | mm | 1350 |
| Material of wheel | PU | |
| Size of driving wheel | mm | Φ250×80 |
| Size of front wheel | mm | Φ78×70 |
| Size of balance wheel | mm | Φ100×40 |
| Min steering radius Wa | mm | 1550 |
| Min stacking aisle Ast | Mm | 1865 |
| Min height of forks G | mm | 85 |
| Max height of forks H | mm | 205 |
| Max. travel speed(laden/undan) | Km/h | 3.5/4.0 |
| Gradeability | % | 5 |
| Brake type | Electromagnetoc | |
| Power of driving motor | KW | 0.7 |
| Power of lift motor | KW | 0.8 |
| Electric controller | Curtis 1212 | |
| Battery capacity/voltage | Ah/ V | 95/24 |
| Weight of battery | Kg | 51 |
| Net weight(no battery) | Kg | 255 |
