Specifications
Rubber Shoe Sole Making machineAuto mold movement system
PLC controll system and touching screen
Rubber Shoe Sole Making Machine
Rubber Plate Vulcanizing press is the machinery which produce all kind of rubber products, and thermosetting plastic like as related specifications aseling products, projected rubber, rubber plate and so on.
This Machinery has three types: frame type, pillar type and jaw type. It is economical advantage of compact structure, high working pressure, and high producing efficency.
Features
1- Material of steel :
Hight quality carbon steel,more thick than other supplier,after shot blasting ,smooth and strong enough,we usually use more thickness material than other supplier.
2- Weldment of frame : world technique
Welded together as a whole part,Stewing fire treatment after weldment.
(Carbon dioxide gas shielded welding,alloyed welding wire).
submerged arc welding, VSR treatment after weldment.
3- Heating way&precision temperature control:
Steam ,oil or Electric
Plate temperature tolerance: ±0.5°C
4- There are more advanced technical information as our core patents,and not showed in the description,please email us.
Model and its Parameter as follows:
Model |
XLB-D400*400*2 |
XLB-D500*500*1 |
|
Nominalmoundingpower(MN)
|
0.50 |
0.5 |
Plate Size(mm) |
400*400 |
500*500 |
Plate pressure(Mpa) |
3.1 |
2.0 |
Piston stRoke(mm) |
250 |
250 |
Distance between hot plate(mm) |
125 |
250 |
Working layer Number |
2 |
1 |
Pressure of working fluid(Mpa) |
16.9 |
16.0 |
Total heat power(KW) |
9 |
6.0 |
Heat type |
Electricity |
Electricity
|
Maximum working temperature(Degree) |
200 |
200
|
Configuration type |
4 pillar |
4 pillar
|
Motor power |
2.2KW,1430R/Min |
2.2KW,1430R/Min
|
