Home > Products > Rubber Product Making Machine > Rubber Mat,Solid Tire,Rubber Seal and Joint Vulcanizer Mould Press/Auto Push Out Rubber shoe sole making machine
Rubber Mat,Solid Tire,Rubber Seal and Joint Vulcanizer Mould Press/Auto Push Out Rubber shoe sole making machine
- 50 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A
You May Like
-
rubber o-ring vulcanizing press machine
-
Rubber Mat,Solid Tire,Rubber Seal and Joint Vulcanizer rubber making machine
-
rubber vulcanized shoe machine
-
Banbury Rubber Kneader Machine
-
Column Tyre Press/Automatical Rubber Sealing Washer Vulcanizing Machine/Rubber Mat Making Machine
-
Industrial Gasket Making Machine/U-Seal,V-Seal Moulding Press China Manufacturer/PLC Control
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Yahua | Model Number | XLB-D500*500*2 | |
| Voltage | 220-380v | Power(W) | 2.2-5.5kw | |
| Weight | 1t | Certification | iso | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1'Plate vulcanizing press2.make oil seal, slipper
3.used for vulcanizing various of rubber products and non-standard product
Good quality with reasonable price.
Easy operation with convenient maintenance.
Low labor intensity and low energy consumption.
Parameters/version
|
XLB350*350*2 |
XLB400*400*2 |
XLB500*500*2 |
XLB600*600*2/4 |
XLB750*850*2 |
XLB1000*1000*2 |
Mould closing force | 0.25 | 0.5 | 0.8 | 1.0 | 1.6 | 2.5 |
Hot plate spacing | 125 | 125 | 125 | 125 | 125 | 200 |
Hot plate layer | 2 | 2 | 2 | 2/4 | 2 | 2 |
Plunger stroke | 250 | 250 | 250 | 250/500 | 250 | 400 |
Heating way | Electricity/stream | Electricity/stream | Electricity/stream | Electricity/stream | Electricity/Stream | Electricity/stream |
Main motor power | 2.2 | 2.2 | 2.2 | 2.2 | 3 | 5.5 |
The thermal power | 2.4kw/board | 3kw/board | 3 | 7.5kw/board | 9kw/board | 10.8kw/board |
Size(l*w*h) | 1450*400*1350 | 1600*400*1440 | 1450*690*1818 | 1880*780*1660 | 2100*1010*1900 | 2400*960*2500 |
Weight(kg) | 1200 | 1500 | 1700 | 2500/3100 | 3560/4300 | 8300 |
Platen unit area pressure | 2.04 | 3.13 | 2.52 | 2.78 | 2.51 | 2.5 |
