Fully Automatic Rubber Product Making Machinery/Rubber O Ring and U Ring Symmetrical Seal Shaping and Curing Press

Construction

1)Four Pillar Type

2)Frame type

3)C-frame type

Control

1)Manual

2)Semi-automatic

3)Fully automatic PLC controlled with touch screen user interface.

Operation

1)Hydraulic Up-Stroke

2)Hydraulic Down-Stroke

3)Hydro-Pneumatic Operation

4)Vacuum Molding Hydraulic Press

Heating:

1)Electrical heaters

2)platens with thermic fluid heating suitability

3)platens with steam heating suitability.

Application:

Our presses are used in variety of application in rubber molding article.

It includes automaotive components, pharmaceutical products, butyl rubber stoppers, rubber traffic safety products, anti-vibration mountings, bridge bearing with testing facility, rubber fenders.

Capacity:-

Tonnage-25 tonne to 10000 tonne

Cylinder ram diameter:100mm to 600mm

Cylinder Strokes:-upto 1500mm

Platen size:- upto 16mtrs X 4mtrs

Model

XLB-1100*5700

XLB-1400*5700

XLB-1400*10000

XLB-1600*8500

XLB-1600*10000

XLB-2000*10000

Plate size

1100*5700

1400*5700

1400*10000

1600*8500

1600*10000

2000*10000

Total pressure

17.55MN

25.00MN

49.00MN

47.60MN

56.00MN

70.00MN

intensity of  pressure

2.8 Mpa

3.13 Mpa

3.5 Mpa

3.5 Mpa

3.5 Mpa

3.5 Mpa

Diameter of piston

500 mm

360 mm

450 mm

500 mm

450 mm

600 mm

Piston number

5

10

20

14

18

16

Piston stroke

520 mm

400 mm

300 mm

300 mm

400 mm

300 mm

Working layer

2

2

1

1

2

1

Clamping force

0.50

0.72

0.90

0.6

1.20

1.20

Drawing force

0.40

0.60

0.80

0.5

1.10

1.00

Steam pressure

0.63 Mpa

0.63 Mpa

0.63 Mpa

0.63 Mpa

0.63 Mpa

0.63 Mpa

Cooling pressure

0.3 Mpa

0.3 Mpa

0.3 Mpa

0.3 Mpa

0.3 Mpa

0.3 Mpa

Operation system

PLC

PLC

PLC

PLC

PLC

PLC

Application

nylon rope belt conveyor, PVG/fabric such as core parallel tape.
