Help CenterJDZW-10 Voltage Transformer 11kv Outdoor Voltage Transformer
Related Products
-
LFSQ-10 Different Types Current Transformers Toroidal Current Transformer Core Current TransformerUS$ 200 - 500MOQ: 10 Sets -
LMZB6-10 10KV Busbar Type Current Transformer Bushing Type Transformer 11kv Dry Type TransformerUS$ 200 - 500MOQ: 10 Sets
-
LQJ-10 High Voltage Transformer in China 11kv Step Down Transformer Special Type TransformerUS$ 200 - 500MOQ: 10 Sets
-
LZJC-10 100VA 50VA 300VA Current Transformer TypeUS$ 200 - 500MOQ: 10 Sets
-
LZK-10 Current Transformer for ZW32 Vcb Types of Winding of Transformer Protective TransformerUS$ 200 - 500MOQ: 10 Sets
Description
The types of outdoor voltage transformer are full cast- resin insulated used in outdoors. They are used for metering electric energy, voltage control and relay protection in the electricnon-useful ground neutral system up to 50Hz or 60Hz and 10kV. The transformers can beexe cuted according to the standards GB1207-2006 and IEC 60044-2.
Technical data
1 .The voltage transformers are in accordance with GB1207-2006 and IEC 60044-2 standards;
2. Power factor of load: COSφ =0.8(lagging);
3. Creep age distance: the product accords with the request of ιι class;
4. The other technical data see following table:
Type |
Rated voltage rated (V) |
Rated output (VA) |
Limit output (VA) |
Weight (kg) |
|
0.2 class |
0.5 class |
||||
JDZW-10 |
10000/220 |
25 |
50 |
300 |
22.5 |
10000/100/220 |
25 |
50 |
200 |
30 |
|
