Home > Electrical & Electronics > Passive Components > Capacitor > CE CQC Aluminum AC Power CBB65 100uF 450V Air Conditioner Capacitor
CE CQC Aluminum AC Power CBB65 100uF 450V Air Conditioner Capacitor
US$ 2 - 25
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Ghorit
Model Number:
CBB65
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BFMR Series High Voltage Shunt/Filter Capacitor 11KV 150KVARUS$ 80 - 500MOQ: 20 Units -
Cbb60 sh Motor Capacitor 250vac 50/60hz 25/70/21US$ 1.5 - 25MOQ: 100 Pieces
-
250v-500v ac Motor Run Capacitor Cbb60US$ 1.5 - 25MOQ: 100 Pieces
-
CBB60 40 70 21 500vac Motor Run CapacitorUS$ 0.5 - 10MOQ: 100 Pieces
-
Motor Run Capacitor Cbb60 sh 50/60HzUS$ 1.5 - 25MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
Ghorit
Model Number
CBB65
Type
Aluminum Electrolytic Capacitor
Application
Other, Apparatus, instrument, household appliances and other AC, DC circuit
Package Type
Surface Mount
Capacitance
1-100UF
Rated Voltage
250~660VAC
Operating Temperature
-25°C to +85°C
Specifications
CBB65 RUN CAPACITORS
Main Feature:
Low dissipation factor small inherent temperature rise, excellent
self-healing stability safety and high voltage withstand etc.
Applications:
Run starting in household electric appliances air conditioner,
refrigerator which demand 50/60Hz AC power supply Have
safe protection constrution.
| Technical features | |
| Operating temperature | 40/70/21,25/85/21 |
| rated voltage | 250-660VAC |
| rated capacitance | 250VAC:1-120UF |
| 450VAC:1-100UF | |
| Tolerance | ±5% |
| Testing voltage | T-T:2.0·Un, 2S no breakdown |
| T-C:2500VAC, 10S no breakdown | |
| Insulation resistance | T-T:≥3000MΩ·UF |
| T-T:≥1000MΩ | |
| Loss tangent | tg≤0.001 (100Hz) |
| Safety class | P0,P2 |
Specifications: can be supplied according to the customers'special need.
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2000
Factory Size
50,000-100,000 square meters
Total Employees
301 - 500 People
