Specifications
Melamine Molded Door Skin Hot Press: Scientific design; Quality quality frame; Easy installation and operation Youming Faith Manufurturing
Main Technical Data of MDF/HDF Melamine Molded Door Skin Hot Press
1) Parameter of Molded Door
| Width | 1150mm |
| Length | 2150mm |
| MDF Thickness | 3~8mm |
2) Rate of Production
| About | 800 sheets/ day (20 hours) |
| Remark | Rate of production depends on board, resign, paper, temperature, pressure etc. |
3) Electric Power
| Power Supply | 380v/ 50 Hz, Three phases, AC |
| Total Power | 30kw |
4)Heating (Prepared by buyer)
| Medium | Thermal oil |
| Capacity of Boiler | 20*104 Kcal/h |
5) Net Weght: Approx 30 ton
We will provide:
1.Seller will send 1-2 technicians to guide the equipment installation and trial run.
2,The installation duration is about 25-30 days.
3.The construction of machine’s foundation support steel blocks.
4. The boiler and pipes & valves connected to the inlets/outlets of machine.
5.Hydraulic oil, thermal oil and fuel for boiler.
6.The necessary device, facilities and skilled worker for the installation and trial run.
7. Electric power, connected to main electric cabinet;
8 The necessary material such as impregnated paper, raw board etc.
9.The other relevant tools for the installation and trial run.
Located at Lanshan district, Linyi City of Shandong province, “the Biggest wood based panel base of Asia”, LINYI XIANGYING MACHINERY MANUFACTURING CO.,LTD(Linyi wood based panel machinery plant)is an aggressive enterprise which integrates woodworking researching, designing ,manufacturing, marketing and service into one whole.
Since it was established in 1992, Xiangying machinery keeping innovations and perfection to commit themselves in producing best quality machinery.
Our main products are Particle board production line, Plywood production line, MDF production line, Melamine veneer press,Mould door equipment etc. based on our good quality as well as perfect service ,our business scope expands extensively both at home and in more than 20 countries such as Vietnam, Malaysia, Pakistan ,Bangladesh, Russia, Turkey and so on. And they are all well praised by our clients.
1. All kinds of mold can be made by customer's drawings
2. All the parameters above just for reference, for they are updating all the time
3. Package: Standard packing
4. Warranty: All the machine enjoys one year’s warranty, in this period.
Any problems of machine, please feel free to contact
