Help CenterHJZ-DISPENSER-6600 High Speed Jetting Glue Dispensing Bezel Glue Dispensing Machine
Related Products
-
Mixed Glue Dispensing Machine .hot Glue Dispensing MachineUS$ 4,200 - 10,000MOQ: 1 Piece -
Semi-automatic Glue Dispensing Machine Dispensing Machine Liquid Dispensing MachineUS$ 5,086.8 - 6,000MOQ: 1 Piece
-
4132Y Medical Dispensing Machine Token Dispensing Machine Coupon Dispensing MachineUS$ 4,200 - 10,000MOQ: 1 Piece
-
3000UV Diesel Dispensing Machine Gasket Dispensing Machine Automatic Glue Dispensing MachineUS$ 4,239 - 5,000MOQ: 1 Piece
-
Polyurethane Dispensing Machine Cnc Dispensing Machine Automated Dispensing MachineUS$ 5,086.8 - 6,000MOQ: 1 Piece
Shenzhen Heng Jin ZhiTechnology Co., Ltd. based in Shenzhen & established in 2014,and specialized in automatic soldering equipment, automatic locking screw equipment, automated dispensing equipment, labeling machines, laser machines, ACF machines, automated assembly line,other high-tech enterprise automation control equipment,standardizedmachines,non-standard machines and related product development, production, sales and import and export.We provided high-speed, high-precision fully automated technology programs with high reliability and flexibility to our customers mainly in the telecommunications, semiconductor, plastic modules, automotive electronics, new energy and other areas. Currently, our products are mainly exported to Europe, America, Southeast Asia and other markets, the main customers include Oticon, Electrolux. Bosch, Flextronics, Foxconn, Panasonic, Philips, Huawei, ZTE and so on. Heng Jin Zhi Technology Co., Ltd. has accumulated years of technology industry experience, adhere to the people-oriented, innovative development concept, to provide 24-hour service to support customer demand, professional engineers to help customers complete the installation, commissioning, training and process improvement. We look forward to providing professional solutions for automated production processes and agents to join us in the global market. Our vision: to become a global manufacturer and marketer of leading automation products. Our mission: to create value for customers.
2. Product Specifications
| Model | HJZ-DISPENSER-6600 |
| Control method | Motion Control Card + industial controller |
| Working area | 250*350mm |
| Optional working area | 450*350mm, 850*500mm |
| Rails loading | 4KG |
| X/Y/Z driving method | Servo motor+ball screw |
| Max travling speed | 1000mm/s |
| Positioning accuracy | +/-0.01mm |
| Repeatiability | +/-0.01mm |
| Weighting system accuracy | 0.1mg |
| Min jetting volume | 0.002ml |
| Available liquid viscosity | 1-2000000cps |
| Volume accuracy | +/-1% |
| Mounted valve | Standard 1 set, will present two sets more |
| Valve heating temperature | 0-100C |
| Com | SMEMA |
| Programming method | Inline or offline visual programming |
| Input power | 220VAC 50-60HZ |
| input pressure | 0.6Mpa |
| Power | 3Kw |
| Machine size | 730*1260*1380mm (can be custimized) |
| Weight | 410kg |
1. The field of application of non-contact jet valve, Z axis without lifting, thereby widening the broader
2. mature and stable high-speed, high-precision motion platform
3. The automatic thermostat to ensure a consistent flow of paint
4. equipped with high-precision weighing system, ensuring consistent glue, reduce material waste, improve productivity and yield
5. The on-line delivery system can communicate with other devices
6. precise positioning and automatic visual visual sampling system
7. Automatic altimeter system, the substrate warpage no effect
8. Windows control software interface is simple, easy programming
9. optionally equipped with injection valves, screw valves and pneumatic valves
10. The modular design can be equipped with an optional arbitrary function item
11. The high-speed jet, the maximum 200 points per second
12. The size can be arbitrarily set point can achieve a smaller diameter dispensing
13. A vacuum cleaner nozzle means
3. Product Feature
1. 0 ~ 7Bar low-voltage operation
2. supplies less affordable
3. minimum injection quantity 0.002 microliters
4. Non-contact, needle-free design
5. maximum injection rate of 3000 times / sec.
6. High accuracy (within 1% by volume)
7. Piezo drives, software correction
8. nozzle may heat, and the temperature distribution
9. using quick release nozzle design, electronic adjustment
10. 1 ~ 2,000,000mPas wide applicability viscosity
By Industry:
11. communications industry: hot-melt adhesives, UV glue, conductive silver paste
12. optical communications industry: silica gel, micro-optical glue dispensing, packaging and other applications
13. biomedicine industry: Biotechnology spermatogonia transport, protein ratio, etc.
14. LED manufacturing: phosphor dispensing, filling potting, LED flexible strip packaging applications
15. Electronics Industry: SMT, PCB board, LCD, components, housings, insulators, etc.
4.Suitable liquid
Various solvents, adhesives, paints, chemicals, glue, etc., including silica gel, EMI Conductive plastic, UV glue, AB Glue, fast rubber, epoxy glue, sealant, hot glue, grease, silver plastic, red plastic, solder paste, thermal grease, solder Paste, lacquer, screw fixation agent, wood glue, anaerobic adhesive, acrylic adhesive, wear rubber, Crystal, potting compound, Horn glue, instant glue, rubber, paint, enamel paint, lacquer, ink, pigments, etc.
6. Applications
• Underfill
• FPC package
• SMT red plastic dot
• Silver Point
• Solder Paste
• LED package
• component package
• Surface Mount
• Precision coating
• a semiconductor chip package
Escrow, Credit card, Union western . You can choose a method which is the most convenient for you.
In order to protect your interests,your payment will be temporarily held by Aliexpress,and will not be released to us until you receive your order and are satisfied with it. So it's very safe for buyers.
We ship to worldwide,but we only ship to your confirmed address. Please make sure your shipping address is correct before purchase.
We ship out your parcel within 3 business days after we get your payments.
Our Service
- On time delivery, 5-8 days deliery time for normal machine,cutomized machine maximum 15 days.
- Provide free training.
- 1 Year warranty except consumption parts.
- 10 hours response time for oversea customers, 72 hours can provide the repair service in customers country. normally we can provde 24hrs on line service. we can arrange our engineer go to oversea customer for training or repair if requested by customer.
- Free for software upgrade.
- Whole life service after warranty.
Quality System: ISO9001
6.Quality Ensurance
- Assembly process control with traveling card.
- 100% finisnl inspection.
- 72hrs running with power before out going.
If item damaged on arrival, please take a picture and contact with us(send us a message on Aliexpress) within 48 hours. We will take care of it. Returned item has to be in its original condition.
Buyer is responsible for return shipping cost(unless item damaged on arrival). After receiving the return we will make a replacement depends on our available stock,
if not available, a refund will be issued.
