Huawei VP9030 1080P Video conference endpoint

Name: Huawei VP9030 1080P Video conference endpoint
Brand: Huawei
Availability: InStock

FOB Price

US$ 4,399 - 4,399 / Unit

1 Unit(Min. Order)

Port hongkong
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Video Conference System	Function	Other, video conference
Simultaneous Interpretation	No	Place of Origin	Guangdong, China
Brand Name	Huawei	Model Number	VC9M3C6VCT01

Product Description

ViewPoint 9030 HD codec(1080P),VPC600 HD camera(12x),VPM210 microphone,Overseas.

Introduction

ViewPoint 9030 is an economical detached High definition group video endpoint that supports the H.264 1080p 30fps encoding technology and 4-site embedded MCU(Optional) with total 8Mbps bandwidth, broadband voice (AAC-LD), and high-definition (HD) data transmission. It provides users with 1080p high definition quality video and high fidelity (Hi-fi) quality audio with the maximum 4Mbps bandwidth to peer to peer communication. It is bringing multi-site, excellent HD video communication and content sharing experience to your conference room in an affordable and simple way.

Product Features

In today’s fast-paced global economy, business is being made between companies and partners distributed around the world, day and night. It is obvious that he who is acting fast upon the market demand will win the game.

ViewPoint 9030 brings people together in HD virtual meeting experience, immediately and enjoyably. Synergy between people creates value, reduces cost and helps you stay ahead of competition.

With a re-designed and trendy remote control GUI (Graphical User Interface), ViewPoint 9030 enables users to operate easily and efficiently, which helps Huawei stay ahead of competition. You will love it.

HD video is nice, but sound effect is more essential during a conference call. By employing AAC-LD, HWA-LD and other standard-based wide band audio technology, ViewPoint 9030 can deliver best of the breed sound experience to make people feel being there.

IP technology is evolving, but there are always times that the live video quality is undermined due to QoS issues. With Huawei SEC (Super Error Concealment ) and IRC (Intelligent Rate Control ) technology, ViewPoint 9030 is able to keep producing good video quality even if there are significant packet loss, latency and jitter over the network.

Worrying about security of your videoconference call? ViewPoint 9030 adopts standard-based H.235 and AES encryption techniques to ensure that your videoconference call is well protected from malicious hacking and sniffing. The device configuration and setup is locked by admin password to avoid any misplay.

To facilitate system integration, ViewPoint 9030 is rack-mountable and equipped with multiple video and audio connections, making it an ideal choice for system integrators.

Specification

Models	ViewPoint 9030-720 ViewPoint 9030-1080
Embedded MCU(Optional)	up to 4 HD/SD 720P video endpoints + 3 voice terminals to join the conference The embedded MCU supports CP, voice activation, camera control, and chairman token two level cascading Mixed H.323 and SIP
Video Standards & Protocols	H.264, H.263, H.263+, H.263++, H.261 H.239 VME(Video Motion Enhancement)
People Video Resolution	1080p 30fps from 1Mbps (Optional) 720p 50/60fps from 768Kbps(Optional) 720p 30fps from 512Kbps 4SIF/4CIF from 256Kbps SIF/CIF from 128Kbps SQCIF/QSIF /QCIF from 64Kbps VideoIntensifier ViewProcessing
Content Video Resolution	Input: DVI-I/VGA interface: VGA(640×480) 60/75/85fps, SVGA(800×600) 60/75/85fps, XGA(1024×768) 60/75/85fps,WXGA(1280×768) 60fps,WXGA(1280×800) 60fps, SXGA(1280×1024) 60fps, 1366×768 60fps, 1440×900 60fps, XGA+(1400×1050) 60fps, 720p 50fps(DVI-I), 720p 60fps, 1080i 50/60fps(DVI-I), 1080p 25/30fps(DVI-I) HDMI/YPbPr interface: 720p 50/60fps, 1080i 50/60fps, 1080p 25/30fps Coding/Decoding resolution: 800600, 1024768, 12801024, 1280720 Output: 800600, 1024768, 12801024, 1280720 Support for dual Live stream mode: 720p(30fps) and 720p(30fps)
Audio Standards & Protocols	AAC-LD Stereo, G.722, G.722.1, G.722.1C,G.711, G.728, G.729A HWA-LD Stereo : Huawei Audio broadband Low Delay Stereo Acoustic Echo Cancellation (AEC) Acoustic Noise Suppression (ANS) 12 dB Automatic Gain Control (AGC) ±6 dB VoiceClear AudioEnhancer
Other Standards	H.221, H.225, H.230, H.231, H.233, H.234, H.235, H.241, H.242, H.243, H.245, H.281, H.283, H.350, H.460, T.140
Network	Standards and protocols: ITU-T H.323/H.320, IETF SIP Network standards: TCP/IP,FTP, FTPS, DHCP, SNMP, Telnet, SSH, HTTP, HTTPS, PPPoE, RTP, RTCP
	Interface	2-port IP, 10/100 Base-T, RJ45 connectors 1-port E1 (Optional ) (H.320), RJ45 connecto 4-port 4E1 (Optional ) (G.703, G.704), RJ45 connectors 2-USB port to access wireless network (WCDMA, CDMA2000 EV-DO) by HUAWEI dongle
	Bandwidth	IP : 64 Kbps~4 Mbps IP: Total 8Mbps (available: Supports up to 4 HD video endpoints + 3 voice terminals to join the conference) E1: 64 Kbps~2 Mbps 4E1: 64 Kbps~4 Mbps
Interfaces	Camera control interface: 2*RS232/422
	Video Input Interfaces	2×DVI-1/YPbPr/VGA
	Video Output Interfaces	2×DVI-I/YPbPr/VGA
	Audio Input Interfaces	1×XLR (Connects to analog microphone) 2×RCA (Stereo, connects to tuning console or VCR) 1×RJ45 (Stereo, connects to microphone array )
	Audio Output Interfaces	2×RCA (Stereo, connects to video recorder) 2×RCA (Stereo, connects to the audio input interface on TV set)
User Interface	Languages: Simplified Chinese, Traditional Chinese, English, German, Spanish, French, Norwegian, Italian, Polish, Russian, Portuguese, Hungarian, Finnish, Romanian, Czech, Swedish, Arabic, Turkish, Greek Control mode: Remote control, Telnet, Web, Wireless Touch panel (Optional)
Security	H.235 signaling and media stream encryption AES media stream encryption Conference access password Conference control password Administrator password H.323 ID and number binding IP address and number binding
Digital Caption	Caption banner, body text and information bar Rolling display mode of the speech draft What-you-see-is-what-you-get (WYSIWYG) caption editing 16 optional colors Modifiable and optional front background color Modifiable caption size and transparency Caption rolling mode setting Site name display and position shift Text input by using the remote control External character generator Powerful caption SMS function enhances the communications among sites and facilitates your use.
Special Features	Integration with Microsoft OCS/Lync Hybrid with IMS Network Power-on picture Picture-in-picture: 1/16 picture size, optional position 16:9 and 4:3 mixed display Split output: Bi-screen and tri-screen display Active caption Group function SiteCall (HD dual stream) Call record Network address book SNP traversal between the public network and private network Intelligent rate control (IRC) Super error concealment (SEC) LDAP API for integration
Maintenance Management	Local and remote loopback Test signals: providing test sound and standard test stripes Volume input indication IP network test Telnet/SSH: command line mode; providing user-level and administrator-level login accounts Local and remote software upgrades Embedded Web server, GUI interface Indication for network package loss Event log record Default settings restoration
Approval and Compliance	CE RoHS
Electrical	Working voltage: 100–240V AC Working frequency: 50–60Hz Power consumption: 100W
Environmental Specification	Operating Temperature: 0-40ºC Operating Humidity: 10-80% Non-Operating Temperature: -40º-85º C Non-Operating Humidity (Non-condensing): 0-95% Peripheral noise: < 46 dBA SPL Lowest illuminance: 15 lux Recommended illuminance: > 300 lux
Physical Characteristics	Codec Dimensions (L×W×H): 422mm×225 mm×60.5 mm Package Dimensions (L×W×H): 485mm×278mm×178mm Weight: 4 kg
