Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > HUAWEI PTN 910F
HUAWEI PTN 910F
US$ 7,131 - 8,150
MOQ: 1 set
Key Specifications
Get Latest Price
Brand Name:
Huawei
Model Number:
optiX PTN 910-F
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
Huawei
Model Number
optiX PTN 910-F
| PartNumber | Model | Description | Software and Hardware Attributes |
| 02310JDF | TNEMHOST0100 | PTN 910-F System,With 4 Channels GE(Optical) ,4 Channels GE/FE(Electric) ,4 Channels FE(Electric) ,8 Channels FE(Optical) and 16 Channels E1(120ohm) | $7131 |
Subrack dimensions (W x D x H) 442 mm x 220 mm x 44.5 mm Full subrack weight 4.8 kg Working voltage (V) -38.4 V DC to -72.0 V DC Power consumption for typical configuration (W) 60 W Switching capacity (Gbit/s) 6.5 Gbit/s/6.8 Gbit/s/10.8 Gbit/s Service slots 3 slots: 1 slot for processing boards and 2 slots for interface boards Environmental requirements -20℃ to 60℃ Storage temperature: -40℃ to 70℃ Relative humidity: 5% to 95%, no condensation or dew Altitude: -60 m to 4,000 m Interface type ADSL2 +, G. SHDSL, Smart E1 (IMA/TDM/ML-PPP), Ch STM-1, FE (optical/electrical), GE (optical/electrical) Max Interfaces GE(o)/8, GE(e)/10, FE(e)/ 20, etc. Service protection scheme Equipment protection: MCU backup; Power Supply Unit backup: Network edge protection: E1 protection:IMA, ML-PPP Ethernet protection:LAG ATM protection:IMA Group Network protection LSP/PW protection:APS 1+1&1:1 protection Ring protection:MPLS-TP Ring protection STP/RSTP/MSTP Clock synchronization 2 channels of external clock inputs/outputs (2 MHz or 2 Mbit/s); supports IEEE 1588/1588v2 ACR, Synchronous Ethernet, TDM clock synchronization QoS feature HQoS Hierarchical scheduling based on port, tunnel, and QinQ link Priority mapping Mapping according to DSCP value, IP priority, EXP value of MPLS, and 802.1p value of VLAN packets Queue scheduling PQ, WFQ, PQ + WFQ Congestion avoidance Weighted Random Early Detection (WRED), Tail Drop policy Traffic shaping Traffic shaping based on port, ATM service, and VLAN CAR Supports Committed Access Rate (CAR) control Traffic classification Simple traffic classification, complex traffic classification MPLS feature MPLS RSVP-TE protocol, LDP protocol, static LSP TDM PWE3 CES over Packet Switched Network (CESoPSN), compliant with RFC 5086; Structure-Agnostic TDM over Packet (SAToP), compliant with RFC 4553; compression of idle timeslots ATM PWE3 N-to-one and one-to-one modes, compliant with RFC 4717 Ethernet PWE3 Ethernet over PW, IP over PW L2VPN Virtual Private Wire Service (VPWS), Virtual Private LAN Service (VPLS), Hierarchical VPLS (H-VPLS) OAM Real-time monitoring and fault detection Ethernet OAM, compliant with IEEE 802.1ag, IEEE 802.3ah, ITU-T Y.1731, GACH+Y.1731; ATM OAM; E1/VC-12 Pseudo Random Bit Sequence (PRBS) error detection; MPLS Tunnel OAM; PW OAM; BFD, LPT, CES alarm transmission; ATM alarm transmission Alarm and performance monitoring Real-time alarm reporting; CES performance monitoring; Ethernet performance monitoring; ATM performance monitoring; MPLS performance monitoring; equipment, board, and port performance monitoring; SNMP V1, V2 alarm performance query Security Equipment security IP source guard, Denial of Service (DoS) attack prevention, Generalized TTL Security Mechanism (GTSM) extension (LDP, BFD, and MSDP), MAC Forced Forwarding (MFF), IEEE 802.1X authentication Management security Authorization and authentication based on user name and password, SSH v1.5 and v2.0, HW Terminal Access Controller Access Control System (HWTACACS) + authentication Unified integrated NMS (U2000) Unified Network Management System (NMS) for transport, carrier, and access equipment; graphical interface; simplified IP network maintenance; click-and-play E2E services configuration; service-based alarm system; alarm suppression; guided troubleshooting; intelligent performance management; and early warning system Remote batch upgrades and comprehensive, intelligent tools improve maintenance efficiency
