HUAWEI PTN 960
US$ 13,517 - 15,448
MOQ: 1 set
Key Specifications
Get Latest Price
Brand Name:
Huawei
Model Number:
optiX PTN 960
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
Huawei
Model Number
optiX PTN 960
| PartNumber | Model | Description | Software and Hardware Attributes |
| 02310WSB | TNDPHOST3400 | PTN 960 System with Protection(3U AC) |
-
Subrack dimensions (W x D x H) 442 mm x 220 mm x 88.9 mm (DC); 442 mm x 220 mm x 133.3 mm (AC) Full subrack weight Less than 8.42 kg Working voltage (V) -38.4 V DC to -72.0 V DC; 90 V AC to 280 V AC Maximum power consumption (W) Less than 250 W Switching capacity (Gbit/s) 44 Gbit/s or 56 Gbit/s Service slots 8 slots, 2 slots for processing boards and 6 slots for interface boards Environmental requirements -5℃ to 55℃ Storage temperature: -40℃ to 70℃ Relative humidity: 5% to 95%, no condensation or dew Altitude: -60 m to 4,000 m Interface type TDM E1, Ch STM-1, FE (optical/electrical), GE (optical/electrical), 10 GE (optical), ATM STM-1 Max Interfaces 10GE(o)/4, GE(o/ 24, GE(e)/24 etc.
Service protection scheme Equipment protection:
MCU backup;
Switch Unit backup:
Clock Unit backup;
Network edge protection:
E1 protection:IMA, ML-PPP
Ethernet protection:LAG
ATM protection:IMA Group
Network protection
LSP/PW protection:APS 1+1&1:1 protection
Ring protection:MPLS-TP Ring protection
STP/RSTP/MSTPClock synchronization One channel each for external clock inputs/outputs (2 MHz or 2 Mbit/s); supports IEEE 1588v2, Synchronous Ethernet, TDM clock synchronization QoS feature HQoS Hierarchical scheduling based on port, tunnel, and QinQ link Priority mapping Mapping according to DSCP value, IP priority, EXP value of MPLS, and 802.1p value of VLAN packets Queue scheduling PQ, WFQ, PQ + WFQ Congestion avoidance Weighted Random Early Detection (WRED), Tail drop policy Traffic shaping Traffic shaping based on port and VLAN CAR Supports Committed Access Rate (CAR) control Traffic classification Simple traffic classification, complex traffic classification MPLS feature MPLS Static LSP TDM PWE3 CES over Packet Switched Network (CESoPSN), compliant with RFC 5086; Structure-Agnostic TDM over Packet (SAToP), compliant with RFC 4553; compression of idle timeslots Ethernet PWE3 Ethernet over PW L2VPN Virtual Private Wire Service (VPWS), Virtual Private LAN Service
(VPLS), Hierarchical VPLS (H-VPLS)OAM Real-time monitoring and fault detection Ethernet OAM, compliant with IEEE 802.1ag, IEEE 802.3ah, ITU-T Y.1731, GACH+Y.1731; E1/VC12 Pseudo Random Bit Sequence (PRBS) error detection; MPLS Tunnel OAM; PW OAM; LPT, CES alarm transmission Alarm and performance monitoring Real-time alarm reporting; CES Performance Monitoring; Ethernet performance monitoring; MPLS Performance Monitoring; equipment, board, port performance monitoring; SNMP V1, V2 alarm performance query Security Equipment security IP source guard, Denial of Service (DoS) attack prevention, Generalized TTL Security Mechanism (GTSM) extension (and Multicast Source Discovery Protocol (MSDP)), MAC Forced Forwarding (MFF) Management security Authorization and authentication based on user name and password, SSH v1.5 and v2.0, HW Terminal Access Controller Access Control System (HWTACACS) + authentication Unified integrated NMS (U2000) Unified Network Management System (NMS) for transport, carrier, and access equipment; graphical interface; simplified IP network maintenance; click-and-play E2E services configuration; service-based alarm system; alarm suppression; guided troubleshooting; intelligent performance management; and early warning system Remote batch upgrades and comprehensive, intelligent tools improve maintenance efficiency
