JYA-CC1EM IP68 waterproof access control standalone 2 door controller with keypad
JYA-CC1EM Introduction:
JYA-CC1EM is a reliable standalone rfid access control for most home usage. With the IP68 waterproof design, it can adapt to most of weather and area and it is convenient even in the bad weather. It can allow 2,000 users use the machine. And this standalone rfid access control allow two door application.
Feature:
>With Anti-theft alarm output for external alarm device
>With bult-in-anti-theft equipments
>Support enrolling cards continuously
>Perfect design, with backlight and fashion silver finish
>Waterproof design for outdoor use
>Strong standalone function device, can be used as WG26reader alone
>Capacity: 2000 user's cards, 2000 codes
>Access ways: cards, code, card + code
>Lower power: static current less than 30mA
>Support only keypad
>Users can reset private passwords
>Wiegand output W26 for card and W34 for codes
>Use keypad to delete lost cards for safety
> Short-circuit protect: when relay or alarm output short circuit, it will shut up in 100µS
Specification:
| Card Type:EM | Waterproof:IP68 |
| Working Voltage:AC/DC12V±10% | Idle Current:≤30mA |
| Reading Range:3~8cm | Operating Temperature:-35°C~60°C |
| Operating Humidity:10%~90% | Lock output load:≤3A |
| Alarm output load:≤20A | Short-circuit protect:≤100μS |
| Door Opening time:0~99 | Dimensions:145*55*22mm |
access control card reader
access control card reader
*Shipping
Based on customer's demands to choose the most economical shipping terms.
Suggest:For sample order ship by Express,for mass order shipping by Air cago or by sea.
We have strong cooperation with DHL,FedEX,UPS,EMS,TNT.
