Product Details
| Place of Origin | Guangdong, China | Brand Name | Joney | |
| Model Number | JYA-LR0703 |
Product Description
15 meter Passive 860Mhz~960MHz long range distance RFID reader UHF
Introduction: standalone RFID Reader uhf rfid reader
JYA-LR0704 is a long distance UHF RFID card reader. Its sensity range can reach 25 meters.
With 860mhz-960mhz frequency, it can allow fast recognition and reaction.
Features: standalone RFID Reader uhf rfid reader
> RS232/WG26/RS485/ RJ45( optional)
> 860Mhz~960MHz,
> Read range can up to 25meters
> Size: 450×450×120mm
Specification: standalone RFID Reader uhf rfid reader
Performance Index | |
Frequency range | 860-960MHZ |
FM mode | FHSS or fixed frequency, set by the software |
RF output | 30dBm adjustable;50Ω load |
Communication interface | RS232,RS485,RJ45,WG26 optioanl |
Communication rate | Serial port 9600~115200bps,RJ45 10Mbps |
GP I/O interface | 12 pin + 4 pin |
Power dissipation | average<5W |
Application software | Provide with API SDK and VC, VB, Java application routines |
Tag Operation Performance | |
Reading distance | up to 15 meters |
Air interface | EPC global UHF ISO-18000-6C(EPC G2), ISO-18000-6B |
Mechanical and Electrical Performance | |
Dimension | 450*450*120mm(excluding mounting bracket and external wiring) |
Power supply | 12V DC |
Weight | 7.0Kg |
Installation | Embrace rod mounting |
Humidity | 5%-95%, non-condensing |
Protection grade | IEC IP65 |
Operation temperature | -20 ºC to +60 ºC |
