3G GPS 4 channel SD card mobile DVR ,4ch AHD mobile DVR
Easily Smart GUI Interface, saving time in device setting.
Product Features
>H.264 Video Compression,multiple steam recording, Support 4CH 720P million pixels HD video recording.support 4CH 720P million pixels AHD input/ 4CH analog SD camera input/ 2CH HD + 2CH SD mixed input ;
VGA output for optiona ;
> High quality real time recording, 720P/CIF/HD1/D1 Optional, quality adjustable;
>Professional Car Power Design,8-36V wide voltage,Provide reverse voltage/overload/short circuit protection, to meet kinds of car application;
>Support 12VDC/2.5Amp output voltage,power supply for Camera/Screen etc;
>Dual SD Card Support, each max 128GB,,protect DVR from shock & Dust damage;
>Watchdog abnormal restart function,protect SD Card and Record;
>Exclusive File System protect data completeness,prevent SD Card fragment;
>ACC Delay off,can set 24 hours;
>Auto Record/Manual Record/Alarm Record etc working mode to meet different requirements;
>Show Car status/Plate/Driving Route/Low Speed/Over Speed information for convenient management;
>Support GPS/BD G-sensor Optional;
>Optional single RS232 serial port or single RS485 extension
>4CH Alarm input(Door Open,Light,Turn direction,brake,reverse etc),can linkage kinds of alarm;
>1CH Alarm Output;
>Support picture snap when alarm;
>Easily Smart GUI Interface, saving time in device setting;
>Can upgrade the software via SD card.
>Stability Aviation plug, easily connecting and high shock proof;
>Be Customized according your request;
Parameter Sheet
Item |
Parameter |
|
OS |
Linux |
|
Language |
Chinese/English/Customized |
|
Video Compression |
H.264 |
|
OSD |
Overlays information such as date time and vehicle ID |
|
GUI |
Graphical User Interface |
Setup system parameters with the remote control. |
Video Record System |
Video Input |
4CH 720P AHD input/SD input/mixed video input,aviation connector, 1.0Vp-p, 75Ω |
Video Output |
1CH CVBS+1CH VGA output, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen |
|
Preview |
Support 1 channel and 4 channels preview.,Support Manual/Alarm Trigger full screen preview |
|
Resolution |
720P/D1/HD1/CIF, MAX:4 channels 720P |
|
Video Quality |
0-7 levels, 0 is the highest level. |
|
Video Standard |
PAL: 100f/s , CCIR625 line,50field; NTSC: 120f/s, CCIR525 line,60field; CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional; HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional; D1: 800Kbps ~ 3Mbps, 8 level video quality optional; 720P: 4Mbps-6Mbps, multi level video quality optional |
|
Record Mode |
The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported. |
|
Audio |
Audio Input |
4CH ,Aviation Plug |
Audio Output |
1CH,Aviation Plug |
|
Compression |
G.726 compression, 8KB/s speed |
|
Alarm Input |
4Ch Alarm Input, kinds of alarm linkage support |
|
Alarm Output |
1CH Alarm Output |
|
Communication interface |
1CH RS232 or 1CH RS485 for optional |
|
Position |
Support Built GPS/BD Module, built in G-sensor, can repaly and analyse vehicle driven route. |
|
wireless transmission |
Suppport Built-in 3G/4G wireless transmission function, WCDMA, CDMA2000, TDD-LTE, FDD-LTE....
|
|
Motion Detection |
Support motion detection alarm. (Can set the video recording duration time after alarm on platform.) |
|
G-Sensor |
Support G-sensor |
|
Storage |
SD |
Dual SD Card,each max 128GB SD Card loop recording |
Upgrade |
Support SD Card remote updating |
|
File Format |
.264 |
|
File System |
Special FAT32 File System |
|
Video Playback |
Video Search |
Search By Record Time/Record Type etc |
Playback |
Max support 4CH Replay /Stop/Fast/Slow at same time |
|
Support forward and backward play at the speed of: x 2,x4,x8,x16. | ||
Voltage & Power |
Power Management |
Wide Voltage.Support Timed/Delay off |
Voltage Input |
DC:+8V ~ +36V |
|
Voltage Output |
+12V 2.5A,+5V 2.5A |
|
Power Consumption |
Normal Working <14W , Stand-by status < 0.5W |
|
Working Environment |
Temperature |
-20℃ to +70℃ |
Humidity |
20% to 80% |
|
Security |
Password |
User/Admin 2 Level Different Password |
others |
Size |
112(W) x36(H) x138(D) mm |
Net Weight |
360g |
|
mobile dvr
