PTZ Control 3.5 Inch TFT LCD CCTV Tester Equipment

Name: PTZ Control 3.5 Inch TFT LCD CCTV Tester Equipment
Brand: Joney
SKU: 128323841

Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Joney

Model Number:

Tester-893

Shenzhen Joney Security Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Joney

Model Number Tester-893

Power Electronic

Specifications

--3.5 inch TFT LCD
--ptz controller
--support 12 hours working time
--UTP cable tester
--video level testing

PTZ Control 3.5 Inch TFT LCD CCTV Tester Equipment

Model/Item	CCTV Tester-893
Video Test
Signal mode	NTSC/PAL (Auto Adjust)
Display	3.5 inch TFT-LCD ,960 x 240 resolution
LCD adjust	Adjustable brightness, contrast, color of LCD
Video IN/OUT	1 channel BNC Input & 1 channel Output
Video Output Mode	1.0 Vp-p
Video Level test
Level test	Video signals measured in IRE or mV
Power Output
Power output	DC12V, 1A
Audio Test
Audio input	1 channel Audio input
PTZ controller
Communication	RS232, RS422 simplex and RS485
PTZ Protocol	Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.customized
Baud Rate	150,300,600,1200,2400,4800,9600,19200bps
Video Signal Generation
Color bar generation	Output 1 channel color bar video signal for testing monitor
UTP CABLE TEST
UTP cable test	Test UTP cable connection state and display in the screen. Read the number of the test box.
PTZ data Capture and display
PTZ Data Test	Capture and Analyze the PTZ data sent from controlling device
PTZ address scanning
PTZ address scan	Search up the ID of PTZ camera
POWER
Power Adapter	DC5V, 2A
Battery	1 pcs Lithium Ion Polymer Batteries, 3.7V DC2800mAh
Rechargeable	4 hours recharging time, work for 15 hours
Low Consumption	Sleeping mode, display battery power state
Other Parameters
Work Temperature	-10---+50
Work Humidity	30%-90%
Dimension/Weight	94mmx175mmx40mm / 360g
