Home > Products > CCTV ACCESSORIES > Low Consumption 3.5'' portable CCTV tester DC12V output power JY-T896
Low Consumption 3.5'' portable CCTV tester DC12V output power JY-T896
- 5000 Piece / Pieces per Month
- shenzhen
- Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Joney | Model Number: | JY-T896 |
Power: | Electronic |
Product Description
Specifications
--3.5 inch TFT LCD--ptz controller
--support 12 hours working time
--UTP cable tester
--video level testing
Low Consumption 3.5'' portable CCTV tester DC12V output power JY-T896
CCTV Tester Features : Protable CCTV Tester
3.5"TFT-LCD, LCD Brightness/Contrast/Color S22aturation are adjustable, NTSC/PAL auto display, Video Level testing, NTSC/PAL colorbar generator, PTZ controller,UTP cable tester, PTZ data analyst, PTZ address scanning, DC12V 1A power output for camera, Audio testing, Optical power meter, Lithium Ion Polymer Battery support 12 hours working time.
CCTV Tester Specification: Protable CCTV Tester
Specifications | |
Screen size | 3.5"TFT-LCD 960(H) X 240(V) resolution |
Signal mode | NTSC/PAL (Auto Adjust) |
LCD adjust | Adjustable brightness, contrast, color of LCD |
Video IN/OUT | 1 channel BNC Input & 1 channel Output |
Video Output Mode | 1.0 Vp-p |
Level test | Video signals measured in IRE or mV |
Audio Input | 1 channel Audio input |
Communication | RS232, RS422 simplex and RS485 |
PTZ Protocol | Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.customized |
PTZ Data Test | Capture and Analyze the PTZ data sent from controlling device |
PTZ address scan | Search up the ID of PTZ camera |
Baud Rate | 150,300,600,1200,2400,4800,9600,19200bps |
Color bar generation | Output 1 channel color bar video signal for testing monitor |
UTP cable test | Test UTP cable connection state and display in the screen. Read the number of the test box. |
Optical Power Meter | testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc. |
Power Adapter | DC5V, 2A |
Backup Battery | 1 pcs Lithium Ion Polymer Batteries, 3.7V DC3000mAh |
Rechargeable | 4.5 hours recharging time, work for 12 hours |
Low Consumption | Sleeping mode, display battery power state |
Work Temperature | Temp:–10°C to 50°C |
Work Humidity | 30%-90% |
Color Box Dimension | 112mmx189mmx47mm |
Standard Kit Weight | 1.35kg |
Application & Functions | |
Application scope | CCTV system installation and maintenance |
The CCTV transmitting channel testing | |
PTZ controller | |
Dome camera and All in one camera testing | |
Basic Functions | DC12V power output to Camera |
1CH audio input | |
Optical power meter, testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc.t. | |
PTZ address scanning, search up the ID of PTZ camera | |
Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment | |
Support RS232 and RS485 interface, the rate 150-19200bps | |
Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection | |
PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset. | |
Support more than twenty kinds of PTZ controller protocols | |
Colorbar Video signal generator, transmit/receive colorful images | |
Automatically identify and adapt the video mode of NTSC and PAL | |
Adjustable brightness, contrast, color of LCD | |
Standard Package List | |
CCTV Tester(Built-in battery) | x1 |
Bag | x1 |
Sling | x1 |
DC5V adapter | x1 |
USB adapter cable | x1 |
485 cable | x1 |
Audio cable | x1 |
Video cable | x1 |
DC12V output cable | x1 |
CAT5 tester | x1 |
Fiber Optic Test Connectors | x1 |
User Manual | x1 |
Color box | x1 |
Services | |
PST offer 2 years product warranty since the date of shipping, unlimited after-sales service | |
Delivery time: within 7 days | |
Payment: Bank wire transfer, Western Union, T/T ,Paypal | |
Shipping: Express(DHL, UPS, FedEx, TNT etc), Air Cargo, by sea, HK post, China Post, EMS | |
24 hours timely tech support via email, skype, MSN, whatsapp, phone etc |
Welcome to visit our website for detailed information
www.joneysecurity.en.china.cn
Company trade terms:
OEM Service:
Your LOGO or company name can be acceptable for OEM orders! We don't charge any cost if your order quantity is 50pcs above each model.
Requested sticker and color box are without any charge!
OEM color box can be made if your order quantity reached 500pcs above!
Many colors optional and your requested color can be made for OEM order!
Deliery Time:Within 7 days after payment is checked
Quality warranty :2 years for free maintain.Whole life service for continue cooperating customers!
Payment term:by L/C,T/T,Western Union,Paypal
Price term:FOB shenzhen
Delivery term:by air,By Express(DHL/FEDEX/TNT/UPS/EMS/CHINA POST)By Sea.
Please contact our Client service! Welcome your inquiry on many more models!
