Glass Printing Machine High Resolution Double Head of NC-SPT2513

Glass Printing Machine High Resolution Double Head of NC-SPT2513 thumbnail-1
Glass Printing Machine High Resolution Double Head of NC-SPT2513 thumbnail-2
Glass Printing Machine High Resolution Double Head of NC-SPT2513 thumbnail-3
Glass Printing Machine High Resolution Double Head of NC-SPT2513 thumbnail-4
Glass Printing Machine High Resolution Double Head of NC-SPT2513 thumbnail-5
Glass Printing Machine High Resolution Double Head of NC-SPT2513 thumbnail-6
Glass Printing Machine High Resolution Double Head of NC-SPT2513 photo-1
Glass Printing Machine High Resolution Double Head of NC-SPT2513 photo-2
Glass Printing Machine High Resolution Double Head of NC-SPT2513 photo-3
Glass Printing Machine High Resolution Double Head of NC-SPT2513 photo-4
Glass Printing Machine High Resolution Double Head of NC-SPT2513 photo-5
Glass Printing Machine High Resolution Double Head of NC-SPT2513 photo-6
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Guangzhou Nuocai Digital Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name NuoCai
Model Number NC-SPT2513
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, Other, Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer, Tube Printer, UV printer/UV printing machine
Automatic Grade Automatic
Voltage 220v
Gross Power 1000w
Dimensions(L*W*H) 400*210*140cm
Weight 1300kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Guangzhou Nuocai Digital Products Co, Ltd

Guangzhou NUOCAI is a high techology company whichspecializes in the digital printing machine and consumables supplies development, production, marketing as well as product processing. With the high skill , advantegeous innovations and high  responsibility teamwork, we spent almost 5 years in researching and developing, while at the same time developing ourown Universal printing  machine and the relevant supply fittings,which become a new techology in the field of DTG digital inkjet printing,blister advertisement ,decoration even in some plan designing.



Glass printing machine high resolution double head of NC-SPT2513



Nuestra empresa es un fabricante profesional de la impresora digital de cama plana, como la máquina de impresión textil y de la impresora UV.Nuestra fábrica está situada en Guangzhou, China.

Recomendamos nuestra máquina de impresión UV grande formato NC-SPT2513 con multi Cabezales de impresion Seiko K1020/508GS a tu.Su max. formato de impresión es 2500x1300mm. Montado con Multi Seiko K1020/508GS cabezales de impresión, se puede llegar a la impresión de buena resolución y alta velocidad. Y puede imprimir directamente en la vidrio, ceramica, madera, metal, plastico, cuir,etc. Nuestra máquina es la calidad estable y user-friendly.



Glass printing machine high resolution double head of NC-SPT2513



Product Glass printing machine high resolution double head of NC-SPT2513
Model No. NC-SPT2513
Unit Price EXW, FOB,CRF,CIF
Payment Term 30% Deposit , the balance before shipping
Print Technology
& Parameters		 Print Technology Digital UV Instantly Curing Print
Print Head Multi Print Heads x 4/5/6/7 (Seiko K1020/508GS)
LED UV Lamps Double LED UV Lamps(Cold light source)
Print Direction Automatic Bi-Direction
UV Ink C M Y K + W / C M Y K LC LM+W/ C M Y K x 2
Resolution 720x720dpi ~ 180x180dpi   (2~16 pass)
Print speed 40m2/H
Ink consumption 1m2/15ml
Print size 2500X1300mm
Softeware PhotoPrint RIP
Operation System Windows 98/2000/XP/Win7
X,Y-Axis control Servo motor systems
Height adjustment Carriage rise/lower automatically
Vaccum suction Independent intelligent air suction system
Print head cleaning Hight power AC motor driven automatic suction
Print head protection Automatic anti-collision system
Interface HI-USB2.0/3.0
Electricity AC220V 50/60HZ
Services 1 Year Warranty , Life-time maintenance
Printer N.W. 1300KG
Printer dimension 4000x2150x1360mm
Packing Fumigation-Free Wooden Case
Print materials metal,glass,wood,bamboo,leather,Plastic,etc









contacto: Derek

TEL: +86-13427616404

Skype: Jimmychan97



  • User-friendly and maintenance-friendly
  • Industrial-used high speed digital UV Printer
  • Intelligent Bi-direction and up to 2 pass
  • Solved the UV white ink clogging problem
  • Characteristic design and personalized production
  • One piece up printing task is avaible and praticable
  • Multi print heads Seiko K1020/508GS Assembled
  • Print mode: White ink + color ink / double color ink

Glass printing machine high resolution double head of NC-SPT2513





Printing:

Glass printing machine high resolution double head of NC-SPT2513

Samples:

                                     Wood Door



                Glass printing machine high resolution double head of NC-SPT2513



                                                Glass

Glass printing machine high resolution double head of NC-SPT2513



                                                         PVC/Plastic



Glass printing machine high resolution double head of NC-SPT2513



                                                                Metal/Aluminium

           Glass printing machine high resolution double head of NC-SPT2513









 Glass printing machine high resolution double head of NC-SPT2513

Glass printing machine high resolution double head of NC-SPT2513 Glass printing machine high resolution double head of NC-SPT2513

 Glass printing machine high resolution double head of NC-SPT2513Glass printing machine high resolution double head of NC-SPT2513
