Large Format High Speed UV Printer Printing Glass Machinery

Large Format High Speed UV Printer Printing Glass Machinery thumbnail-1
Large Format High Speed UV Printer Printing Glass Machinery photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Brand Name:
Nuocai
Contact Supplier Request Quote Chat Now
Guangzhou Nuocai Digital Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Brand Name Nuocai
Model Number NC-SPT2513
Usage Card Printer
Automatic Grade Automatic
Voltage 220V
Gross Power 4000W
Dimensions(L*W*H) 3940*1940*1320mm
Weight 2000KG
Certification CE
After-sales Service Provided Overseas service center available

Specifications

large format UV printer printing glass machinery
High speed Seiko print head
2500*1300mm printing size
Double LED lamp
CE

                                             large format high speed UV printer printing glass machinery





Specification



Mode

NC-SPT2513

EXW Price



Printhead

SPT1020GS (35PL)

Number of printhead

6 Pieces

Printing speed

2pass

26sqm/h

4pass

18sqm/h

6pass

10sqm/h

Maximum printing width

2440*1220mm(96″X 48″) (L*W)

Printer Dimension

3940*1940*1320mm

Packing Dimension

4200*2200*1600mm(14.8CBM)

Gross Weight

2000kg

Power

AC220 50HZ/60HZ, 4KW

Print height

80mm

Rip Software

Photoprint

Drying system

Double Large LED lamp

Applicable materials

Acrylic, metal, plastic, ceramic tile, wood, stone, glass,

acrylic, PVC, crystal, textile, leather, etc

Features

1. Industrial SPT print head (High speed)



2. Negative pressure ink supply system without   any manual operation



3.Intelligent crashproof to protect printhead



4.Automatic height measuring system



5.Adopt Japan SMC,Omron,Schneider components and parts to

 improve stability



6. Special qualified ink develop by Seiko company





Charaters of Seiko printhead

SPT-1020 printhead

Original Japanese piezo spt-1020 printhead which features with 1020 active nozzles and long usable life to produce

high quality output at 720dpi resolution.

1. Original Japanese printhead with steel plate, which ensure long life.

2. 71.8mm printing width.
2. 4/6 color plus 720dpi, high color matching rate and high resolution.
3. The voltage of the printhead, automatically adjustable to the temperature,

  prevents blockage caused by the change of temperature.

4. Edge feather function can blur the pass line and feather the pass edge.

5. Special qualified ink manufactured by Seiko company

6. Good cost performance





Sample printed



large format high speed UV printer printing glass machinerylarge format high speed UV printer printing glass machinery







 Technical Support we offer

Nuocai: We offer a series of technical support :

·  3-7 Days free technical training in our factory

·  1 Year warranty , lifelong maintenance

·  Operation demo disk

·  English manual

·  Online support

·  On-site maintenance on required

·  Professional trade guidance

·  Different workable printing solution







Company info

Guangzhou Nuocai digital products Co.,Ltd is a leading manufacturer and global distributor of

digital flatbed printer, parts and consumables . By providing the world with top quality digital

flatbed printer at competitive factory price , we enjoy great reputation from customers all over the world .



Since the establishment in 2005 , our R&D team members are constantly staying ahead of the

market and developed lots of automatic flatbed digital printer. From presale consultancy to after sale

service , from OEM printing project planning to ODM business , our technicians and sales are ready

 to offer you assistant at any time if you order large format high speed UV printer printing glass machinery

large format high speed UV printer printing glass machinery



large format high speed UV printer printing glass machinerylarge format high speed UV printer printing glass machinery
