Help CenterPE PP Plastic Drink Straw Extrusion Machinery Unit/ball Pen Refill Tube Machine
Related Products
-
Hot!Multi-layer Small Pipe Production Line Plastic Machinery ExtruderUS$ 20,000 - 50,000MOQ: 1 Set -
Multi-layer Small Pipe Production Line / Plastic MachineryUS$ 20,000 - 50,000MOQ: 1 Set
-
PE PP Drink Straw Unit-plastic Machinery ExtruderUS$ 10,000 - 30,000MOQ: 1 Set
-
PE PP Drink Straw Unit in Plastic MachineryUS$ 10,000 - 30,000MOQ: 1 Set
-
Polychromatic!Plastic Cotton/lollipops Stick/pen Refilling Tube/ Drink Straw Swab Stick Extruder Making MachineUS$ 20,000 - 50,000MOQ: 1 Set
Specifications
1.manufacturer of plastic machinery for pipe production line2.Passed ISO9001 CE
3.the unit can be used into many fileds
1.Drink straw maker introduction
(1)SJ-Drink straw machine series is composed of frequency conversion extrusion machine, mould, vacuum diameter-fixed device etc
(2).Available for monochromatic, dichromatic, tricolor, four color and etc. Application: The machines are wildly used for producing drink straw. nozzle. cotton. slip. lollipop stick tooth pick. ball-pen core. watercolor pen core. toy tube .drop tube and other small industrial irregular shape pipes.
2.Main technology parameter
|
Model |
|
Monochromatic Straw Machine |
Dichromatic Straw Machine |
Tree color Straw Machine |
Four color Straw Machine |
|
Model of Extruder |
Screw die |
φ45 |
φ45φ25 |
φ45φ25 |
φ45φ25 |
|
Main Screw L/D |
25:1 |
25:1 |
25:1 |
25:1 |
|
|
Motor |
7.5kw |
7.5kw or 2.2kw |
7.5kw or 2.2kw |
7.5kw or 2.2kw |
|
Take up and cutting |
Inverter |
0.75kw×2 |
0.75kw×2 |
0.75kw×2 |
0.75kw×2 |
|
Capability |
Extruder output |
25-35kg |
25-35kg |
25-35kg |
25-35kg |
|
Product length |
>5mm |
>5mm |
>5mm |
>5mm |
|
|
Product dir |
0.8mm-8mm or 0.8mm-13mm |
0.8mm-8mm or 0.8mm-13mm |
0.8mm-8mm or 0.8mm-13mm |
0.8mm-8mm or 0.8mm-13mm |
|
|
|
900 |
1000 |
1200 |
1300 |
3.The benefits our company bring to you
(1)We are in the field of Plastic machinery for over 5 years, but our technology engineer have been working in this filed for more than 30 years, we providing the qualified plastic profile, plates. pipes, granules extrusion lines.
(2)Various plastic material like PVC,PP,PS,ABS,PE,PPR, PEX, CPVC, UPVC,HDPE,LDPE, PERT,PB,GRP are processed.
(3)The quality of our machines meet the standards of ISO9001 and CE certificate and export to many countries,
Our customers feedback to us that the quality is reliable.
(4)The prices of our machines are reasonable. We don't do one-shot deal and we expect long-term cooperation.
4.Our products
(1).Machines of cold and warm pipes ,gas pipe,ground heating pipe,agricultural irrigation pipes,drainage and vent pipes, power and cable pipes ,chemical drainage pipes.
(2).Building decorative plates, sheets and wood plastic composite profile extrusion line .
(3)Plastics recycling and reprocessing machinery
(4)All kinds of auxiliary machines of plastic pipes, granules, plates, profiles.
5. Machine photo show
If you want more detailed information, pls don't hesitate to contact Tracy
We can offer you photos, detailed specification, video, our experienced engineer will offer you professional suggestions before and after the order.
