Specifications
Specifications1, Production experience
2, Technical professional
3, Safe and energy-saving
The characteristics of the boiler:
(1) compact structure, easy installation and migration, cover an area of an area small, infrastructure investment.
(2) the flue gas through mandatory rotation scour convection bank, make full use of the heating surface, improve the efficiency of boiler.
(3) because the flue gas return loop, completely achieve the goal of furnace dust removal.
(4) the water seal slag to prevent the spread of dust, is a new type of green environmental protection product.
The boiler parameters :LSB series
| Rated evaporation capacity | 0.3t/h | 0.5t/h | 0.7t/h | 1t/h |
| Rated steam pressure | 0.4MPa 0.7MPa | |||
| Rated steam temperature | 151°C 170°C | |||
| Feed water temperature | 20°C | |||
| Heating area | 13.2m² | 22m² | 29.7m² | 41.2m² |
| Grate area | 0.5m² | 0.78m² | 1.13² | 1.54² |
| Ontology water volume | 1.33m² | 1.33m² | 1.76m² | 2.25m² |
| Design of fuel | Smokeless coal gas | |||
| Boundary dimension(ΦxH)mm | 1620x3650mm | 1920x4086mm | 2126x4490mm | 2333x4766mm |
The scope of application of steam boiler:
Can be used in textile, printing and dyeing, paper making, food, rubber, plastics, chemicals, pharmaceuticals, steel,metallurgy, etc. For enterprises, institutions, hotels, schools, restaurants, etc., to provide heating, bathrooms, air conditioning and hot water.
1. Simple structure, convenient operation
2. Easy maintenance, small footprint
3. Low investment
4.Small area needed
Product picture:
