Home > Industrial Equipment & Components > Boiler & Furnace > Boiler > Pellet Boiler Chain Grate

Pellet Boiler Chain Grate

Name: Pellet Boiler Chain Grate
Brand: Yongxing
SKU: 128207223
Availability: InStock

US$ 1,500 - 150,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Natural Circulation

Usage:

Industrial

Contact Supplier Request Quote Chat Now

Henan Yongxing Boiler Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

hongkong/tianjin/shanghai or others

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Natural Circulation

Usage Industrial

Structure Other

Pressure High Pressure

Style Horizontal

Fuel Coal-fired

Place of Origin Henan, China

Brand Name Yongxing

Model Number 2T/4T/6T/8T/10T/15t/20t

Output Steam

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1:High-performence and environmental steam boiler
2.enhance the intensity and heat transfer effect

The chain grate stoker is a mechanization equipment applied mostly in steam boiler, hot water boiler and thermal oil boiler. It features reasonable structure, reliable performance and convenient installation, etc.

The series products adapt light chain grate stoker and reasonable air distribution device and also strengthen the seal at both sides of chain grate as well as configuration reasonable front and back arch.

It features strong suitability in combustion and reasonable air distribution for combustion and quick fire starting. Operation practice provided that combustion heat value is about 18840 kJ/kg.

Soft coal with more than 20% of volatile amount and mixed coal can be combusted normally. Moreover it can also combust waste industrial materials such as wood block, sugarcane residual, etc

It features strong suitability in combustion and reasonable air distribution for combustion and quick fire starting. Operation practice provided that combustion heat value is about 18840 kJ/kg.

Soft coal with more than 20% of volatile amount and mixed coal can be combusted normally. Moreover it can also combust waste industrial materials such as wood block, sugarcane residual, etc

Applicable boiler	active grate area (m2)	Stoker height (mm)	wheel base (mm)	active grate width (mm)	Width between two endplates (mm)	Length of shaft out of grate (mm)	Height of shaft out of grate (mm)	Dia. of shaft out of grate (mm)	Qty of wind chamber
2t/h	6.20	940	5800	1274	1390	1000	655	Φ80	5
4t/h	4.64	825	4200	1274	1390	920	540	Φ80	4
4t/h	5.81	750	4300	1274	1590	1137	470	Φ80	4
6t/h	9.25	880	5220	1994	2110	1295	598	Φ80	8
6t/h	8.19	890	5000	1854	1970	1282	603	Φ80	5
6t/h	7.41	800	4910	1714	1830	1200	513	Φ80	4
8t/h	9.60	880	5400	1994	2110	1295	598	Φ80	5
10t/h	11.50	860	6250	2034	2150	1357	575	Φ95	5
10t/h	10.86	999	6325	1992	2108	1390	715	Φ95	5
10t/h	12.11	1050	6000	2354	2470	1620	760	Φ100	5
10t/h	11.52	992	6260	2034	2150	1357	710	Φ95	5
10t/h	12.11	1050	6000	2354	2470	1620	760	Φ100	5
15t/h	18.41	1050	7000	2994	3110	1950	765	Φ100	5
15t/h	18.41	1050	7000	2994	3110	1950	765	Φ100	5
20t/h	23.14	1050	7500	3444	3560	2175	765	Φ130	6
20t/h	20.62	1060	8510	2674	2790	1690	773	Φ125	8
25t/h	24.11	975	8100	3280	3430	2075	688	Φ130	7
