Our Hydraulic stone splitting machine is suitable for splitting all types of natural and artificial stones, cube stone/curb stone/wall stone/blockstone/tiles/pavingstone/countertops/vanity tops.
It has floating teeth up and down,we also called it individual chisels which can maHydraulic stone splitting machine tch the natural surface of the stones perfectly.
Every splitting machine can be integrated in a production line, especially designed according to your needs.
The main characters of our machines are:
1. The electrical control cabinet adopt the French Schneider, with internal layout reasonable and neat, and
through the senor switch to facilitate rapid signal to make the movements of the machine consecutive and accurate.
2.The hydraulic system adopts from German Bosch Rexroth, providing sustainable,stable and sufficient
power to the machine.
3.With intelligent gear cutting head, itcould adjust itself according to the smooth condition of the stone surface.
4. We can design a perfect stone cutting line from blocks to paving stone, wall stone, mosaic, cobble stone, etc, upon the demand of customers
1.The standard model we have:
Model No. |
BRT320-1200*800-M |
BRT160T-500*550 |
BRT70T-400*350 |
BRT40T-240*320 |
BRT20T-160*180 |
splitting pressure |
320T |
160T |
70T |
40T |
20T |
max.splitting width |
1200mm |
500mm |
400mm |
240mm |
160mm |
max.splitting height |
800mm |
550mm |
350mm |
320mm |
180mm |
adaption of upper/lower blade |
36*20mm |
30*15mm |
20*10mm |
15*10 |
10*7mm |
rated power |
22KW |
15KW |
11KW |
11KW |
7.5KW |
rated voltage |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
electric current |
42.5A |
30A |
22.6A |
22.6A |
15A |
main oil cylinder data |
Φ400/Φ280-850 |
Φ280/Φ200-600 |
Φ200/Φ140-360 |
Φ160/Φ110-340 |
Φ110/Φ80-200 |
oli advanced speed |
40mm/s |
76.6mm/s |
108mm/s |
167mm/s |
96mm/s |
overall size(L*W*H) |
2370*1500*3840mm |
1970*1200*3300mm |
1500*1200*2520 |
1260*1000*2300 |
1145*1000*2030 |
weight |
8000KG |
5300KG |
3200KG |
2900KG |
|
C front type:
Bridge type:
2.Our new design and what we customize for our customers:
3.The finished products you can make:
4.Project Cases
5.Parts and components:
6.Production:
7.Packing:
8.Production line:
1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2. Handling time for an order
Within 30 days supplied from stock
3. Shipping way
Normally it is by sea
4. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
5. After-Sale Services:
a. Our sales team will reply for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time
c. Free replacement will provide once the failure confirmed caused by our product quality
