Diesel Driven Hydraulic Concrete Splitter
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BESTLINK
Model Number:
BS36/38/40 BS42/45
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
BESTLINK
Model Number
BS36/38/40 BS42/45
Condition
New
Products features:
Hydraulic concrete & rock splitter is one of the efficient, safest and easiest ways of mining,quarring, demolition & removing mass and reinforced concrete.
Hydraulic Splitter models and parameters: BS36/38/40 BS42/45
Driven Mortor: Electric / Diesel / Gasoline / Pneumatic.
BS36/38/40 uses Iron Cylinders, BS42/45 have both Iron and Aluminium Alloy cylinders.
Besides, we already successfully copied the same cylinder from German Darda. It have the exact same shape, same parts and same performance as the original one.
Products technical data:
Pump pack Technical data
1. Technical data of Diesel engine
| Power model | overall size(mm) | Weight(kg) | Oil pumping station reserves(L) | Engine Power | Working pressure(MPa) | flux(L/m) | Towable of splitter quantity(pc) |
| Diesel engine | 1150*1180*940 | 260 | 40 | 5.15KW | 55-60 | 2-13 | 1-10 |
2. Technical data of Gasoline engine
| Power model | overall size(mm) | Weight(kg) | Oil pumping station reserves(L) | Engine power | Working pressure(MPa) | Flux(L/m) | Towable of splitter quantity(pc) |
| Gasoline model | 1200*1170*800 | 100 | 40 | 7.5HP | 55-60 | 2-13 | 1-10 |
3. Technical data of electric engine
| Power model | overall size(mm) | Weight | Oil pumping station reserves (L) | Engine power | Working pressure(MPa) | Flux | Towable of splitter quantity(pc) |
| (kg) | (L/M) | ||||||
| Electric motor | 23 | 5 | 0.75KW(220V/380V) | 55-60 | 0.7 | 1 | |
| 384*280*620 | 75 | 30 | 3KW(380V) | 55-60 | 2 | 1-3 | |
| 7.5KW(380V) | 55-60 | 13 | 1-10 |
4. Technical data of pneumatic model
| Power model | overall size(mm) | Weight | Oil pumping station reserves (L) | rotating speed(r.p.m) | Rated power(kw) | Oil flux(L/m) | Working pressure(MPa) | Towable of splitter quantity(pc) |
| Air motor | 384*280*620 | 70kg | 30 | 2000 | 4.10 | 2-13 | 55-60 | 1-10 |
Hydraulic splitting cylinder Technical data
| Model | bore diameter required | Min. bore depth required | Splitting distance | Splitting time | Theoretic spliting power | Actual split power | Cylinder weight |
| BS36 | Φ36-38mm | ≥300mm | 10-40mm | 5-12s | 615T | 320T | 20kg |
| BS38 | Φ38-40mm | ≥400mm | 10-40mm | 5-12s | 615T | 380T | 22kg |
| BS40 | Φ40-42mm | ≥500mm | 10-40mm | 5-12s | 680T | 420T | 23kg |
| BS42 | Φ42-45mm | ≥600mm | 10-40mm | 5-12s | 780T | 480T | 32kg |
| BS45 | Φ45-48mm | ≥800mm | 10-40mm | 5-12s | 826T | 500T | 33kg |
Accessories Technical Data
| Name | Model | Unit | weight(kg) |
| Lubricating grease | Special for hydraulic splitter | Tin | 2 |
| oil distributor | with 3 outlet | pc | 1 |
| Oil Pipe | standard configuration | set | 1 |
| Transportation frame | set | 42 |
More pictures for your reference:
Here is the pictures for the rock splitter storage and more models for your reference:
Working pictures
Here is the pictures to show the hydraulic rock splitter in the work site.
