Wall Demolition Tools Diesel Driven Hydraulic Rock Splitter
- Xiamen
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | BESTLINK | |
| Model Number | BS36/38/40 BS42/45 | Condition | New |
Exported standard Plywood crate for Wall Demolition Tools Diesel Driven Hydraulic Rock Splitter
Product Description
Products features:
Products technical data:
Pump pack Technical data
1. Technical data of Diesel engine
| Power model | overall size(mm) | Weight(kg) | Oil pumping station reserves(L) | Engine Power | Working pressure(MPa) | flux(L/m) | Towable of splitter quantity(pc) |
| Diesel engine | 1150*1180*940 | 260 | 40 | 5.15KW | 55-60 | 2-13 | 1-10 |
2. Technical data of Gasoline engine
| Power model | overall size(mm) | Weight(kg) | Oil pumping station reserves(L) | Engine power | Working pressure(MPa) | Flux(L/m) | Towable of splitter quantity(pc) |
| Gasoline model | 1200*1170*800 | 100 | 40 | 7.5HP | 55-60 | 2-13 | 1-10 |
3. Technical data of electric engine
| Power model | overall size(mm) | Weight | Oil pumping station reserves (L) | Engine power | Working pressure(MPa) | Flux | Towable of splitter quantity(pc) |
| (kg) | (L/M) | ||||||
| Electric motor | 23 | 5 | 0.75KW(220V/380V) | 55-60 | 0.7 | 1 | |
| 384*280*620 | 75 | 30 | 3KW(380V) | 55-60 | 2 | 1-3 | |
| 7.5KW(380V) | 55-60 | 13 | 1-10 |
4. Technical data of pneumatic model
| Power model | overall size(mm) | Weight | Oil pumping station reserves (L) | rotating speed(r.p.m) | Rated power(kw) | Oil flux(L/m) | Working pressure(MPa) | Towable of splitter quantity(pc) |
| Air motor | 384*280*620 | 70kg | 30 | 2000 | 4.10 | 2-13 | 55-60 | 1-10 |
Hydraulic splitting cylinder Technical data
| Model | bore diameter required | Min. bore depth required | Splitting distance | Splitting time | Theoretic spliting power | Actual split power | Cylinder weight |
| BS36 | Φ36-38mm | ≥300mm | 10-40mm | 5-12s | 615T | 320T | 20kg |
| BS38 | Φ38-40mm | ≥400mm | 10-40mm | 5-12s | 615T | 380T | 22kg |
| BS40 | Φ40-42mm | ≥500mm | 10-40mm | 5-12s | 680T | 420T | 23kg |
| BS42 | Φ42-45mm | ≥600mm | 10-40mm | 5-12s | 780T | 480T | 32kg |
| BS45 | Φ45-48mm | ≥800mm | 10-40mm | 5-12s | 826T | 500T | 33kg |
| Name | Model | Unit | weight(kg) |
| Lubricating grease | Special for hydraulic splitter | Tin | 2 |
| oil distributor | with 3 outlet | pc | 1 |
| Oil Pipe | standard configuration | set | 1 |
| Transportation frame | set | 42 |
More pictures for your reference:
Here is the pictures for the rock splitter storage and more models for your reference:
Working pictures
Here is the pictures to show the hydraulic rock splitter in the work site.
Company Profile
Xiamen Bestlink Factory Co., Ltd. is committed to providing the best drilling and cutting machines, tools and accessories products in marble and granite stone quarrying, as well as in civil engineering application, especial demolition project. Our company is now a leading manufacturer of cutting and drilling equipment for the extraction of marble, granite and ornamental stones in China. Since 1985, we have produced and supplied high quality Split AG Non-Explosive Demolition Agent to our worldwide customers in the quarrying and demolition industries. From early 2000, we have made a start in the study and developed the Hydraulic Rocks and Concrete Splitters by patent inventions, and reached a great success in the domestic and overseas market. Now, we are only a producer and exporter just now from China. In 2004, we developed and produced the patented products: Hydraulic Rock Drill, Stone holes Groover, Stone Crack Expander and Hydraulic Rock Breaker. We offer a vast range of hydraulic and pneumatic drills and machines for diamond wire cutting as well as all kinds of accessories for quarrying activities. Now, quality products are being exported to more than 45 countries and regions all over the world including the USA and Europe with high reputation. We are continually looking for ways to develop drilling and cutting technology for quarrying and demolition, and hoping to be the world NO.1 company about quality and prices of hydraulic Splitters and Expansive Cement within 5 years. Thank you very much for your support and wish to get your deep interest and be your best partner.
