Home > Products > Gasoline rock drill > petrol rock drill
petrol rock drill
- 1000 Set / Sets per Month
- Xiamen
- T/T
Product Details
Condition: | New | Type: | Core Drilling Rig | Power Type: | Other |
Place of Origin: | Fujian, China | Brand Name: | BESTLINK | Model Number: | Y24 |
Usage: | Other, Rock drilling | Voltage: | 220V | Power(W): | 1000W |
Dimension(L*W*H): | 72*30*22cm | Weight: | 20kg | Certification: | CE |
Warranty: | 1YAER | After-sales Service Provided: | Overseas third-party support available |
Packaging Details
catron
Product Description
1. Pneumatic rock drilling machine includes: Y6, Y20, Y24, and Y26(hand held), YT24 and YT28(air leg).
This type rock drills use compressed air as power, mainly used in construction sites, various types of mines, tunnel, railways, water conservancy construction and national defense construction areas for drilling operations.
YT24 YT28 pusher leg rock drills always works with support air leg, can be used for any angle drilling.
Y6, Y20, Y24, and Y26 hand held rock drills works without air leg, mainly use for downwards drilling.
2. Gasoline rock drilling machine includes: YN27, YN27C and YN27J.
This type rock drill adapt to outside situations where there is no water, no electronic power and no air compressor. It's a kind of hand held rock drill with gasoline engine, air pump and rotation plumbum equipment for running or stop. It can be used for breaking, drilling, blasting, tamping splitting and ramming.
Sansung supplied rock drilling machines have following advantages:
1. Reasonable design 2. Light weight
3. Convinient operation 4. High efficiency
5. Fast drilling velocity 6. Low Air consumption
7. Long life parts etc.
Product specifications:
Type | Weight | Air consumption | Bore Dia. | Drilling depth | Air pressure |
Y6 | 6kg | ≤9.5 L/s | Φ20 mm | 0.5 m | 0.4 Mpa |
Model | Weight | Air consumption | Length | Shank | Bore Dia. | Drill depth | Impact rate | Hose connection |
kg | L/s | mm | mm | mm | m | Hz | mm | |
Y20 | 18 | 26 | 605 | 22*108 | 30-42 | 3 | 30 | 16 or 19 |
Y24 | 23 | ≤50 | 604 | 22*108 | 30-42 | 3 | 34 | 16 or 19 |
Y26 | 25 | ≤60 | 608 | 22*108 | 30-42 | 3 | 38 | 16 or 19 |
Model | Weight | Air consumption | Length | Shank | Bore Dia. | Impact rate | Air Hose connection | Water Hose connection |
kg | L/s | mm | mm | mm | Hz | mm | mm | |
YT24 | 24 | 67 | 678 | 22*108 | 30-42 | 31 | 19 | 13 |
YT28 | 26 | 81 | 661 | 22*108 | 30-42 | 37 | 25 | 13 |
Company Profile
Xiamen Bestlink Factory Co., Ltd. is committed to providing the best drilling and cutting machines, tools and accessories products in marble and granite stone quarrying, as well as in civil engineering application, especial demolition project. Our company is now a leading manufacturer of cutting and drilling equipment for the extraction of marble, granite and ornamental stones in China.
Since 1985, we have produced and supplied high quality Split AG Non-Explosive Demolition Agent to our worldwide customers in the quarrying and demolition industries.
From early 2000, we have made a start in the study and developed the Hydraulic Rocks and Concrete Splitters by patent inventions, and reached a great success in the domestic and overseas market. Now, we are only a producer and exporter just now from China.
In 2004, we developed and produced the patented products: Hydraulic Rock Drill, Stone holes Groover, Stone Crack Expander and Hydraulic Rock Breaker. We offer a vast range of hydraulic and pneumatic drills and machines for diamond wire cutting as well as all kinds of accessories for quarrying activities.
Now, quality products are being exported to more than 45 countries and regions all over the world including the USA and Europe with high reputation.
We are continually looking for ways to develop drilling and cutting technology for quarrying and demolition, and hoping to be the world NO.1 company about quality and prices of hydraulic Splitters and Expansive Cement within 5 years. Thank you very much for your support and wish to get your deep interest and be your best partner.
