Silicon rubber heater with temperature sensor
1. Features
-Silicone rubber heater is composed by nickel alloy foil and silicone heat insulating cloth.
-It is very flexible and can be contact closely with the heated object.
-The shapes, sizes can be making different in various applications.
-Sensors, thermostat, fuse can be added into the heater to testing and control the temperature.
2. Application
-Medical industry (CPAP equipment, medical analyzer, X-ray film machine, CT machine, etc.)
-Transportation industry (EV battery, high-speed rail, car washer, etc.)
-Electron industry (semiconductor pipeline, LCD, camera, printer, etc.)
-Power sector (cabinet, high & low voltage switch, etc)
-Petrochemical industry (drum, tank, etc.)
3. Technical data
-Size: min 25*25mm, max 800*3000mm
-Thickness: 1.0 to 2.0mm
-Voltage: 3V to 380V
-Power density: 0.1 to 5w/cm2
-Max temp: 250℃
-Max continuous working temp: 200℃
Our heaters are with one year guarantee period and the wroking life of design is 50000 hours to 100000 hours.
Company certification: ISO9001:2008, ISO 14001
