GOOD!! PET!. Sheet Extrusion Line /PET sheet making machine/PET sheet production line

Specifications

1.Latest design
2, servo motor control
3. reliable performance
4. produce transparent sheet

It adopts co-extrusion technology, which produce multi-layer co-extrusion PET sheet, such as APET/PETG. PETG/APET/PETG. APET/RPET/APET.



Main technical parameters:

Model No.	Applicable material	Screw size	Layer&structure	Sheet Thickness	Sheet width	Output capacity	Power consumption
AF100-800	APET/PETG/RPET	Φ100x33	Single layer	0.15-1.2mm	800mm	200-220kg/hr	280kw
AF120-1000	APET/PETG/RPET	Φ120x33	Single layer	0.15-1.2mm	800mm	280-320kg/hr	330kw
AF90/65-800	APET/PETG/RPET	Φ90x33 Φ65x33	Double A-B or A-B-A	0.15-1.2mm	800mm	300-350kg/hr	350kw
AF100/65-1000	APET/PETG/RPET	Φ100x33 Φ65x33	Double A-B or A-B-A	0.15-1.2mm	1000mm	350-400kg/hr	385kw
AF-120/65-1000	APET/PETG/RPET	Φ120x33 Φ65*33	Double A-B or A-B-A	0.15-1.2mm	1200mm	460-500kg/hr	435kw

1. It adopts co-extrusion technology, which produce multi-layer co-extruded PET sheet, such as APET/PETG. PETG/APET/PETG. APET/RPET/APET.
2. It is widely used in making plate,trays, and other package material.
3. Gradient three-roll calender,make the operation and maintenance more convenient.
4. It adopts servo motor control for calender roller which grarantee stable thickness and good finishing of final product.
5. There is indivicual motor for calender roller.  Also can be in synchronization
6. It adopts PLC control,the actual parameter setting, data and the feedback operation, the alarm and other functions of automation
