CE Smd Led 3528 Neon Sign Channel Letter Light

CE Smd Led 3528 Neon Sign Channel Letter Light thumbnail-1
CE Smd Led 3528 Neon Sign Channel Letter Light photo-1
US$ 0.1 - 0.25 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Model Number:
ADS-26072
Chip Material:
Other, Epistar chip
Emitting Color:
Other, White,blue,green,yellow,red, white&green&blue&red&yellow
Contact Supplier Request Quote Chat Now
Shenzhen Aidisen Optoelectronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number ADS-26072
Chip Material Other, Epistar chip
Emitting Color Other, White,blue,green,yellow,red, white&green&blue&red&yellow
Luminous Intensity 3000mcd
Luminous Flux(lm) 14lumen
Power Other, 0.24
Power Dissipation 0.24
Color Temperature 3000K-3500K,6000-7000K,10000-15000K
Operating Temperature(℃) -40, 60
Storage Temperature(℃) -50, 60
Place of Origin Guangdong, China
Brand Name ADS
Certification CE

Specifications

1,from factory LED SMD 3528 module light
2,50.000 hours lifespan
3,CE/Rohs certification
4,Epistar chip with high lumen

Advantages:

1,direct from factory with lower price
2,50.000 hours lifespan
3,CE/Rohs certification
4,Epistar chip with high lumen

5, OEM/ODM accept

6, 3-5 days delivery time from our Shenzhen factory



3528 LED Module features:



1, ADS-26072 series module used plastic shell, PCB plate,grey&white wire(thermostability,cold-resistant,resistant to UV)


2, With 2pcs 3528 SMD LED,with large abd uniform angle, no shadow,low thermal resistance,low brightness declines,


3, work effciently under the harsh environment.Energy saving,environment-friendly,long life span for 50,000hrs


4, Suitable for super thin super small channel letters backlighting and so on


5, This module can be linked up to 20pcs at max, more than 20pcs is strictly prohibited,


6, The diameter of power cord should be based on the actual maximum current, the product power,
cable length(recommend no more than 6meters)and the voltage of transmission line.



Specification:

Items Color LED Qty Lumen Wavelength LEDS PCB Dimension units
ADS-26072 Red 2 pcs 5 619-635k 3528 SMD 24*5*0.6mm 20pcs
Green 10 512-528k
Blue 3 463-475k
Yellow 3 584-595k
warm white 14 3000-3500k
white 14 6000-7000k
cold white 14 9000-15000k



3528 2 leds module light parameters:

Items Parameter unit
Power 0.24 W
Voltage DC12V V
Temperature -40-60
IP Grade IP66
dimension 26*7*4 mm
lifespan 50 000 hours
view angle 120
Chip type Epistar



Others featurs :

1) Working voltage: 12V DC
2) Two SMD 3528 LEDs
3) Dimensions:  26x7x4mm
4) Energy efficient, major reduction in power costs
5) Long service life 50,000 hours ,virtually no maintenance during lifetime.
6) Low heat, high brightness, works well under harsh conditions
7) Power consumption: 0.24Watt

9) White,Red,Yellow,Green,Blue color
10) Solid-State, High Shock Vibration Resistant
11) Waterproof and non-waterproof are alternative.



Application


1, Advertisement signs Backlighting
2,Channel Letter Backlighting
3, Advertisement Light boxes and Billboards Back lighting

4, Landscape, commercial, home and stage decoration

5, Using for word advertising signs, advertising light box, LED luminous characters, bars, KTV interior decoration



LED Exhibition:

AidisenLED 2011  Exhibition







1. Exhibition Name Middle East Sign & Graphic Imaging 2011
Place: Dubai Airport Expo, Dubai
Date: 24-26th Jan, 2011
Booth/Stand Number U25

2. Exhibition Name LED China 2011
Place China Import and Export Fair Pazhou Complex, Area B, Guangzhou
Date 1st Mar. To 4th, Mar., 2011
Booth /Stand Number: G581

3. Exhibition Name Euro-Reklama Outdoor EXPO 2011
Place Poznan International Exhibition Centre, Poland
Date 12-15th Apr. 2011
Booth/Stand Number: Confirmed soon

4. Exhibition Name Expopublicitas 2011
Date 25th, May to 27th, May., 2011
Venue: Mexico city, Mexico
Booth/Stand Number: 1303

5. Exhibition Name: LED Shanghai 2011
Date: 2011 6~9th July
Venue: Shanghai, China
Booth No. 552(E1 HALL)

6. Exhibition Name: Serigrafia Sign 2011
Date: 21th, July. To 23th, July., 2011
Venue: Expo Center Norte - Sao Paulo, Brazil
Booth/Stand Number: 245-G

7. Exhibition Name: Expo Sign & Serigrafia
Date: 2011 4-6th August
Venue: Buenos Aires, Argentina
Booth/Stand Number: 1836

8. Exhibition Name: Sign Africa 2011
Date: 2011 24~26th August
Venue: Johannesburg, South Africa
Booth No. J8

9. Exhibition Name: Hong Kong International Lighting Fair(Autumn Edition)
Date: 2011 27-30th October





CE smd led 3528 neon sign channel letter lightCE smd led 3528 neon sign channel letter lightCE smd led 3528 neon sign channel letter light

 ADS-26072W-35X

CE smd led 3528 neon sign channel letter lightCE smd led 3528 neon sign channel letter light
