60mm 18led Full Color Amusement Rides Led Point Light
US$ 1.7 - 1.7
MOQ: 1 Piece
Key Specifications
Get Latest Price
LED Light Source:
SMD 5050 LED
Input Voltage(V):
DC24V
Lamp Power:
2.8
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3leds Amusement Park Pixel Lamp 26mm Led LightNegotiableMOQ: 100 Pieces -
Waterproof 26mm 3 Points Rgb Led Pixel Amusement Park LightNegotiableMOQ: 100 Pieces
-
Led Amusement Light 24v Funfair LightUS$ 0.7 - 0.7MOQ: 1 Piece
-
Waterproof 24v/12V Led Point Light Source Rgb Led Amusement ParkNegotiableMOQ: 100 Pieces
-
35mm Smd Led Driver ic Ucs1903 Smd 5050 Addressable Rgb PixelNegotiableMOQ: 100 Pieces
LED Light Source
SMD 5050 LED
Input Voltage(V)
DC24V
Lamp Power
2.8
Lamp Luminous Flux(lm)
R76/G120/B72/Y72/W216
Working Temperature(℃)
-40, 60
Working Lifetime(Hour)
50000
Lamp Body Material
PC
IP Rating
IP65
Certification
CE
Emitting Color
RGB
Place of Origin
Guangdong, China
Brand Name
ADS
Model Number
ADS6018G
ADS-6018-DC24v led pixel light:
| 1. ADS-6018-DC24 is made of plastic shell and PCB board and transparent 2 fight male and female buckle (high temperature, cold, anti-UV) combination, including monochrome 18PCS 5050 SMD LED. | |||||||
| 2. This product has high brightness, low power consumption, long life, low voltage, low attenuation, rich colors and other characteristics. Product color variety, bright colors. power supply can be DC24V. | |||||||
| 3. Products used in amusement parks, game rooms, hotel, KTV entertainment and other indoor and outdoor decorative lighting. | |||||||
| 4.This product can be up to a series 10PCS, non-super-series, the thickness of the power cord should be based on the actual maximum current that may arise, the product power, cabling length (recommended no more than 5 meters) and low-voltage transmission line voltage drop may be. |
ADS-6018-DC24V Single color led point source parameters:
| Item | Parameter | Unit |
| Voltage | DC24 | V |
| Power | 3.6 | W |
| Working Temp | -40-60 | °c |
| IP Grade | IP66 | |
| Dimension | 60*H65 | MM |
| Lifespan | ≥50000 | h |
| Viewing Angle | ≥140 | ° |
Dimension:
Installation Diagram:
A.Conneact DC24V transformer
B.The transformer 220V voltage
Picture:
