Qingdao Automatic Plastic cup thermoforming machine price
The machine set takes Expandable Polystyrene and zinc stearate as raw material, steam foaming, after two steps of foaming can produce cup and bowl. PLC control production. high level of automation, low labor intensity; high productivity, low cost. producing process adopt complete shut-off design in order to prevent from getting in touch with air while raw material expanding, making the cups and bowls good quality. Fully use energy sources and reduce forming time.
Suitable Sheet: |
PP/PS/HIPS/PVC/PET |
Forming Area: |
650mm x 320 mm |
Forming Depth(Max) |
130mm |
Sheet thickness: |
0.3mm-2.0mm |
Sheet width(max): |
650mm |
Max. Sheet Roll of Diameter: |
800mm |
Forming Speed(max): |
≤35 times/min |
Adjustable Travel: |
100mm-350mm |
Oil Pump Motor: |
11kw, 6grades |
Plug Motor Power: |
4.4kw |
Feeding Motor Power: |
3.0kw |
Rewinding Motor Power: |
0.37kw |
Heating Power: |
60kw |
Rated Power: |
80kw |
Actual Power: |
55kw |
Compressed Air: |
About 0.6-0.8pa/1.6M3 |
Heating Type: |
Top + bottom IR Ceramic Heaters |
Temperature Control Module |
PID, K-type |
Type of Mould |
Multi cavity 1-4rows |
Cutting Type: |
In-mold cutting automatically |
Water Supply: |
About 0.5M3/H |
Overall Dimension(mm): |
about L6000×W2000×H2700 |
Weight: |
About 4.5T |
Responsible for the installation and debugging,equipment warranty for one year.
