rechargeable electric bicycle batteries 48v lifepo4 battery 10ah

Specifications

electric bicycle batteries 48v lifepo4 battery 10ah
1)Long cycle life (2000 times)
2)Environmentally-friendly
3)safety &UL

  rechargeable electric bicycle batteries 48v lifepo4 battery 10ah









NO.	Item		General Parameter				Remark
1	Standard capacity(0.2C)		10Ah
2	Rated voltage		48V
3	Standard charge/discharge current		2A/10A				0.2C/1C
4	Max Continuous discharge current		25A				2.5 C
5	Peak discharge current		50A				5C
6	Battery dimension		as you demands				Could be customerized
7	Weight(Approx,including case)		as light as possible
9	Model		IFR 32650
10	Case material		steel case for single cells
11	Max.Charge voltage		58.4V
12	Cut-off voltage		40 V
13	Charge method (CC/CV)	Standard	CC	0.2C		58.4V cut off
			CV	58.4V		0.05C cut off
		Rapid	CC	1C		58.4V cut off
			CV	58.4V		0.05C cut off
14	Operate temperature		Charge		0°C~45°C
			discharge		-20°C~60°C
			storage		-20°C~55°C

















1. Safety: safest Li-Ion battery, CE UL approved, built-in BMS, none fire, none explosive



2. Clean and Green energy, no toxic material contained



3. Powerful: HP battery can discharge in 15C~20C



4. Long life cycle, > 2000 times deep cycle 80% capacity left,8 times of lead acid battery



5. No memory effect,highly efficient charge anytime, no reduction of capacity



6. Operation temperature: -20~70°C



7. Small size and light weight: 1/2 size of lead acid battery, 70% size of Ni-MH/Ni-Cd battery, 1/2 weight of lead acid battery



8. Good performance at high temperature and high temperature resistance



9. Low self-discharge rate: < 3% monthly















1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car



2. Light electric car: e-bike, electric scooter,e-motor, electric golf car, forklift, cleanness car, electric wheelchairs



3. E-tool: electric drill, electric saw, lawn mower and so on



4. Remote control cars, boat, aircraft, toys



5. Solar and wind power generation energy storage devices



6. Small medical equipment and portable equipment

































Optimum Battery Co., Ltd is one of the largest Lithium battery manufacturers withISO9001 and TS16949 certificates in China, specializing in LiFePO4 batteries with UL. CE. RoHS, IEC-62133 etc certifications for 7 years.



There are about 1500 staffs including 113 engineers producing batteries widely used in EV, HEV, telecommunication stations, e-bikes, e-motorcycles, UPS, solar/wind energy storage solution, home application ect..



Contact nancy Now! Skype: nancy.chen668
