rechargeable 24v 10ah lithium ion battery with charger for electric bike battery

Specifications

24v 10ah lithium ion battery with charger for electric bike battery
1)Long cycle life (2000 times)
2)Environmentally-friendly

rechargeable 24v 10ah lithium ion battery with charger for electric bike battery



















12V 5/10/20/25/30/40/50/60/80/100/120/150/200/300/400Ah



24V 5/10/15/20/30/40/50/60/70/100/120/150/200/300/400ah



36V 9/10/15/20/30/50/60/100/200/400ah



48V 10/15/20/25/30/40/50/100/200/300/400ah



72v.......







 24v 10ah parameters



24v 10Ah LiFePO4 lithium-ion UPS battery
Case material		Steel case for single cell
Standard capacity(0.2C5A)		10A
Rated voltage		24V
Max.charge current		29.2V
Cut-off voltage		20V
Max.charge current		0.5 C5 A
ntinuous discharge current		5 C5 A
Size		as your demands
Approx weight		about 3 Kg
Imdepance(Max, at 1000Hz)		≤50 mΩ
Charge method (CC/CV)	Standard	CC	0.2C	14.6V cut off
		CV	14.6V	0.05C cut off
	Rapid	CC	1C	14.6V cut off
		CV	14.6V	0.05C cut off
Operature temperature	Charge	0°C~45°C
	Discharge	-20°C~60°C
	Storage	-20°C~45°C















1. Safety: safest Li-Ion battery, CE UL approved, built-in BMS, none fire, none explosive



2. Clean and Green energy, no toxic material contained



3. Powerful: HP battery can discharge in 15C~20C



4. Long life cycle, > 2000 times deep cycle 80% capacity left,8 times of lead acid battery



5. No memory effect,highly efficient charge anytime, no reduction of capacity



6. Operation temperature: -20~70°C



7. Small size and light weight: 1/2 size of lead acid battery, 70% size of Ni-MH/Ni-Cd battery, 1/2 weight of lead acid battery



8. Good performance at high temperature and high temperature resistance



9. Low self-discharge rate: < 3% monthly













1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car



 2. Light electric car: e-bike, electric scooter,e-motor, electric golf car, forklift, cleanness car, electric wheelchairs



3. E-tool: electric drill, electric saw, lawn mower and so on



4. Remote control cars, boat, aircraft, toys



5. Solar and wind power generation energy storage devices



6. Small medical equipment and portable equipment
