UPS / Electric Wheelchair Lifepo4 Rechargeable Battery , 12V 20Ah Lifepo4 Battery Pack
- Components: lithium iron phosphat
- Voltage: 12v
- Weight: 3.5kg
- Nominal Capacity: 20ah
- Application: electric bike/scooter, electric wheel chair,golf trolley
- cut-off voltage: 10v
- standard charge current: 0.2C
- life cycle: more than 2000times, 8-10years
- warranty: 2years,
- color: green, blue,silver,black
- terms of payment: T/T
Application
1.Electric vehicles: HEV/PEV, Electric bus, Electric bicycle, Electric boat, Electric tricycle, Electric quadricycle, Electric scooter, Electric wheelchairs, Golf cart, Marine, Station/SUV /wagon/Caravan, E-tour car, Forklift, etc.
2.Solar and wind power system:Solar energy storage, PV system, Solar street light, Wind power generation energy storage, etc.
3.Medical devices:Energy power for various kinds of medical devices, etc.
4.Other electric tools and equipments: Lawn mower, Electric saw, UPS, backup storage system, Military equipments, etc.
Specification
| NO. | Item | General Parameter | |||
| 1 | Cell Model | IFR 32650 | |||
| 2 | Casing Material | Steel Case for Single Cells | |||
| 3 | Standard Capacity | 20Ah | |||
| 4 | Rated Voltage | 12V | |||
| 5 | Max Charge Current | 4A | |||
| 6 | Discharge Cut-off Voltage | 10V | |||
| 7 | Self Discharge Rate | ≤3% one after month | |||
| 8 | Max Continuous Discharge Current | 2.5C5A | |||
| 9 | Standard Charge Current | 0.2C5A | |||
| 10 | Weight(Approx, including case) | About 3.5kg | |||
| 11 | Impedance(Max, at 1000Hz.) | ≤ 20mΩ | |||
Advantage
1.High safety: CE, UL approved, safest Li-ion battery so far, with internal protection circuit board(BMS),no fire,no explosion.
2.Green energy:no toxic material contained.
3. Long life cycle: more than 2000 times deep cycle at 1C rate, 6-8 times of lead acid battery
4. No memory effect: highly efficient charge anytime, no reduction of capacity
5. Operation temperature: -20~65°C
6. Smaller size, lighter weight and high capacity: 1/2 size of lead acid battery, 70% size of Ni-MH Ni-Cd battery, 1/2 weight of lead acid battery
7. Good performance at high temperature and high temperature resistance
8. Low self-discharge rate: < 3% monthly
9. High cost performance
Shipping
1. We will ship the products within 15 working days after receipt of payment.
2. We can ship to you by UPS/FEDEX/DHL/TNT/EMS and so on. Other shipping terms can also be arranged according to specific requirements.
3. We are not responsible for any accidents, delays or other issues that are the responsiblility of the shipping service.
