SK 1325 fabric cloth laser cutting machine
- 200 Set / Sets per Month
- Qingdao Shanghai
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | SK | |
| Model Number | 1325 | Certification | CE |
Product Description
Specifications
SK 1325 fabric cloth laser cutting machine1.DSP offline operation,LCD screen
2.Blade table with vaccum
3.Water protection
SK 1325 fabric cloth laser cutting machine
Applicable Industry
1. Engraving beautiful patterns and words such as wood, bamboo, Ivory, leather, marble, shell etc
2. Mainly used in large plastic character cutting, color plate engraving, organic glass engraving and cutting, sign engraving, crystal engraving, trophy engraving, authorization engraving, etc.
3. Leather Clothing Processing Industry: Can engraving and cutting complex patterns on genuine leather, synthetic leather, leather, woolens, clothing, furnishings, glove, handbag, shoes, hats, toys, etc.
4. Model Industry: Production of construction sand table model and Aircraft Model, etc. ABC plate cutting, MLB cutting.
5. Packing Industry: Engraving and printing rubber plate, plastic plate, double board, die cut plate, etc.
6. Other Industry: Engrave on marble, granite, glass, crystal and other decorative materials, cut paper, card.
Reci Laser Tube Reci Power Supply
Software Control Panel
Technical parameters:
Model | Laser cutting machine SK1218 |
Working area | 1200*1800mm |
Laser tube power | 60W/80W/100W/130w/150w( optional) |
Laser tube type | Sealed CO2 laser tube, water-cooling, 10.6um |
Life of laser tube | 1500 hours or 10000 hours reci tube |
Max Engraving speed | 0-60000mm/min |
Cutting speed | 0-30000mm/min |
Cutting thickness | 1-20mm acrylic (others determined by the material ) |
Resolution ratio | <0.01mm |
Location precision | <0.01mm |
Min shaping character | Chinese 2*2mm,English1*1mm |
Support graphic format | DST, PLT, BMP.HPGL,DXP and AI |
Software supported | CorelDraw, AutoCAD, Photoshop |
Power supply | AC110-220V 50-60HZ |
Operating temperature | 0– 40 centigrade degrees |
Operating humidity | 5%-95% Free of condensed water |
Interface | USB |
Assistant equipment | Exhuast-fans, water pump, air pump |
Driving system | stepper |
Control system | DSP |
Consuming power | <1,000W |
Net weight | 450 KGS |
Gross weight | 600 KGS |
Package size | 240*175*136 CM |
Blade Table CW5000 chiller
