Chain Block

US$ 1 - 3 MOQ: 1 Set

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Model Number:

HSZ

Hebei Chenli Rigging Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tinjin Seaport

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name CL

Model Number HSZ

Usage Construction Hoist

Power Source Hand Chain

Sling Type Chain

Maximum Lifting Weight 20 T

Maximum Lifting Height 20 M

Specifications

1)capacity:05T--20T
2)TUV&GS,CE
3)high quality with low price
4)carton packing
5) G80 alloy steel chain

	HSZ series chain block is designed with a transmission mechanism of
		symmetrically arranged two-step spur gears.
		It can auttomatically brake with the friction plate and pawl brake system.
		Tire high durability and efficiency make it popular all over the world as well
		asthe high quality and competitive price.

Rmarks:inaddition to the standard lift we accept orders to 12m lift.

Model		HSZ-1/2	HSZ-1	HSZ-1/2	HSZ-2	HSZ-3	HSZ-5	HSZ-10	HSZ-20
Capacity T		0.5	1	1.5	2	3	5	10	20
Standard lifting height (m)		2.5	2.5	2.5	2.5	3	3	3	3
Test load (T)		0.75	1.5	2.25	3.0	4.5	6.25	12.5	25
min Headroom (hook to hook) Hmin (mm)		240	270	347	380	470	600	710	1000
Chainpull to lift full load (N)		221	304	343	314	343	381	392	392
No.of load chain fall lines		1	1	1	2	2	2	4	8
Diameter of bad chain (mm)		6	6	8	6	8	10	10	10
Dimensions (mm)	A	120	142	178	142	178	210	358	580
	B	108	122	139	122	139	162	162	189
	C	24	28	34	34	38	48	64	82
	D	120	142	278	142	178	210	210	210
Net weight (Kg)		8	10	16	14	24	36	68	155
Gross Weight (Kg)		10	13	20	17	28	45	83	193
Packing mcasurement (LWaH) cm		28x21x17	30x24x18	34x29x20	33x28x19	38x33x20	45x39x24	55x51x29	70x46x75
Extra weight per meter of extra lift (Kg)		1.7	1.7	2.3	2.5	3.7	5.3	9.7	19.4
