Home > Manufacturing & Processing Machinery > Lifting Equipment > Lifting Sling > Webbing Sling Pure100% PE

Webbing Sling Pure100% PE

US$ 1 - 2.22 MOQ: 1000 Units

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

Model Number:

Contact Supplier Request Quote Chat Now

Hebei Chenli Rigging Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

TIANJIN SEAPORT

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name CL

Model Number EB

Type Webbing Sling

Shape Flat

Material Polyester

Lifting Capacity 5-Ton

Sling Color Red

Lifting Eye Type Flat Eye

Certification CE,TUV&GS

Specifications

Material: 100% high pure polyester
Safety Factor: 6:1,7:1,8:1
Working Load Limit: 1-30T
Certificate: GS,CE, ISO9000

Webbing sling is a sling, consisting of high tenacity continuous multi- polyester woven
webbing with woven edges,sometimes attaching end-fittings for fastening.It goes in a
variety of different types,in order to serve a particular application.

Material: 100% high tenacity polyester

Safety Factor: 6:1,7:1,8:1

Working Load Limit: 1-12T

Certificate: GS,CE, ISO9000

Standard: EN1492-1

width 30-300mm,
thickness 3.5-40mm,

No. of Ply: single,duplex,            three-ply, four-ply

Product Name:

Max.SWL=Mode Coefficient P*Rated Working Load Max.SWL of lifting method
Code	Color	Minimum Breaking Load (Kg)	Rated Working Load (Kg)	UprightP=1 (Kg)	ChokedP=0.8 (Kg)	Angle 45 P=1.8 (Kg)	Angle 90 P=1.4 (Kg)
EB-01		6000	1000	1000	800	1800	1400
EB-02		12000	2000	2000	1600	3600	2800
EB-03		18000	3000	3000	2400	5400	4200
EB-04		24000	4000	4000	3200	7200	5600
EB-05		30000	5000	5000	4000	9900	7000
EB-06		36000	6000	6000	4800	10800	8400
EB-08		48000	8000	8000	6400	14400	1120
EB-10		60000	10000	10000	8000	18000	14000
EB-12		72000	12000	12000	9600	21600	16800
EB-20		120000	20000	20000	16000	36000	28000
EB-30		180000	30000	30000	24000	54000	42000

Specification Information:
Usage of Webbing sling:
  When selecting a sling to carry a given load, it is important to consider the angle at which the
sling is to be used.As an example, one sling in a basket hitch or two slings attached to one
crane hook are different applications involving different sling angles.The degree of the angle
will determine how much the capacity will be reduced.Take the angle between the sling leg
and the horizontal, then multiply the sling's rating by the factor provided in the accompanying
table.


The capacity of a sling will be reduced as the angle from the horizontal is reduced.In the
example below,you will see how the 1,000 pound capacity of a sling used in a vertical
basket hitch is reduced:

Types of Webbing Sling Eyes
   The types of eyes are in accordance with their applications in the fixed working environment,
and many times it can attach end-fittings in order to expand its usages. Users can choose
the most suitable type to proceed with the work smoothly and improve the productivity.
