Rock drill YSP45

Application:

YSP45 is stoper rock drill applied in mining, tunneling or rock drilling work, to drill up holes with angle to the earth within the range from 60^o to 90^o and also can be used for bolting work and shaft sinking work.

Product features:

The stoper rock drill, YSP45, is of robust design for tough working condition. It has high impact frequency and is mainly used for production drilling, raise driving and bolting

Main Parameter:

Weight                                                                                   44kg

Mini. length (mm)                                                                 1420

Max. length (mm)                                                                  2170

Stroke position diameter (mm)                                              74

Piston diameter (mm)                                                             95

Piston diameter (mm)                                                             47

Air pressure      ( at 5kg/cm2)                                           air consumption (L/s)                         ≤83

                                                                                          impact frequency (Hz)                       ≥47

Rotation (r/min)                                                                                  350

Air hose inner diameter (mm)                                                             25

Quality Air Leg Rock Drill Manufacturer In China -FAQ

Delivery time:10 days after deposit

Supply ability:1000 pcs per month.

If you want to get more information,please contact me.

Name:Eric Qin

Skype id:hargrand163
