4" Galvanized Steel 90 Degree EMT Tubing Elbows Made in China
We are a professional company certified by ISO 9001-2000, All our products are corrosion and high temperature resistant, Today, we have managed to garner a good reputation by providing high quality products, efficient service and competitive price.
1)OD:1/2"~80"
2)WT:sch5~sch160 XXS
3)Standard: ASME, ANSI, BS, DIN, JIS
|
Norminal Pipe Size DN |
Outside Diameter at Bevel D |
Center to End |
Center to Center |
Back to Faces |
||||||||||
|
45ºElbow H |
90°Elbow F |
180°Elbow P |
180°Elbow K |
|||||||||||
Series A |
Series B |
Long Radius |
Long Radius |
Short Radius |
Long Radius |
Short Radius
|
Long Radius
|
Short Radius
|
||||||
15 |
21.3 |
18 |
16 |
38 |
-- |
76 |
-- |
48 |
-- |
|||||
20 |
26.9 |
25 |
16 |
38 |
-- |
76 |
-- |
51 |
-- |
|||||
25 |
33.7 |
32 |
16 |
38 |
25 |
76 |
51 |
56 |
41 |
|||||
32 |
42.4 |
38 |
20 |
48 |
32 |
95 |
64 |
70 |
52 |
|||||
40 |
48.3 |
45 |
24 |
57 |
38 |
114 |
76 |
83 |
62 |
|||||
50 |
60.3 |
57 |
32 |
76 |
51 |
152 |
102 |
106 |
81 |
|||||
65 |
76.1(73) |
76 |
40 |
95 |
64 |
191 |
127 |
132 |
100 |
|||||
80 |
88.9 |
89 |
47 |
114 |
76 |
229 |
152 |
159 |
121 |
|||||
90 |
101.6 |
-- |
55 |
133 |
89 |
267 |
178 |
184 |
140 |
|||||
100 |
114.6 |
108 |
63 |
152 |
102 |
305 |
203 |
210 |
159 |
|||||
125 |
139.7 |
133 |
79 |
190 |
127 |
381 |
254 |
262 |
197 |
|||||
150 |
168.3 |
159 |
95 |
229 |
152 |
457 |
305 |
313 |
237 |
|||||
200 |
219.1 |
219 |
126 |
305 |
203 |
610 |
406 |
414 |
313 |
|||||
250 |
273.0 |
273 |
158 |
381 |
254 |
762 |
508 |
518 |
391 |
|||||
300 |
323.9 |
325 |
189 |
457 |
305 |
914 |
610 |
619 |
467 |
|||||
350 |
355.6 |
377 |
221 |
533 |
356 |
1067 |
711 |
711 |
533 |
|||||
400 |
406.4 |
426 |
253 |
610 |
405 |
1219 |
813 |
813 |
610 |
|||||
