Specifications
9060 High Precision Acrylic laser plywood cutter machine1.900*600mm honeycomb table
2. Reci laser 80w/ 120w/150w
3.CE&FDA
9060 High Precision Acrylic laser plywood cutter machine
Applicable material
Non-metal materials ,such as double color board, plexiglass, glass,bamboo wood ,rubber .marble ,granite ,tiles ,leathers,etc
Sample display
SK9060 CO2 laser engraver Reci 80W 120W 150W for engrave and cut
Technical parameter of SK9060 laser graver machine
Model |
SK9060 |
Working area |
900mm*600mm |
Engraving accuracy |
0.025mm |
Resetting positioning accuracy |
±0.1mm |
Graphic supported |
BMP, HPGL, PLT, DST, DXP, and AI |
Driving system |
Stepper |
Control panel |
English |
Drive type |
Step motor |
Engraving speed |
0-60000mm/min |
Cutting speed |
0-30000mm/min |
Laser power |
60W,80W |
Max power |
1 KW |
Laser tube type |
CO2 laser glass |
Communication Interface |
USB2.0 |
Power |
AC110-220V 50-60 HZ |
Operating temperature |
0 - 45°C |
Operating humidity |
8 - 95% |
Engraver For Curve Surfaces(Yes/No) |
No |
Water Cooling(Yes/No) |
Yes |
Laser Tube life |
10000hours |
Recommended Spare Parts/Consumables |
Laser Tube, Focus lens, Reflection lens,Rotary attachment |
Net weight |
250kg |
Gross weight |
320kg |
Packing volume |
2.2 CBM |
MOQ |
1 Set |
Spare parts
Features:
1. Front and rear hole to pass long materials
2. Modern design and beautiful appearance
3. Use imported Taiwan Hiwin linear guide, more durable and high precision
4. Water protection switch ,safety switch and limit switch
5. Adopt DSP control system, and USB offline operation,LCD screen
6. powerfull production ability,can produce all kinds of laser machines, like double head laser, four head laser ,CCD camera laser,auto feeding fabric laser cutter,YAG metal laser engraver,separate marble laser etc.
