Hot Sale Trailer Mounted Water Well Drilling Rig

Hot Sale Trailer Mounted Water Well Drilling Rig thumbnail-1
Hot Sale Trailer Mounted Water Well Drilling Rig thumbnail-2
Hot Sale Trailer Mounted Water Well Drilling Rig thumbnail-3
Hot Sale Trailer Mounted Water Well Drilling Rig thumbnail-4
Hot Sale Trailer Mounted Water Well Drilling Rig thumbnail-5
Hot Sale Trailer Mounted Water Well Drilling Rig thumbnail-6
Hot Sale Trailer Mounted Water Well Drilling Rig photo-1
Hot Sale Trailer Mounted Water Well Drilling Rig photo-2
Hot Sale Trailer Mounted Water Well Drilling Rig photo-3
Hot Sale Trailer Mounted Water Well Drilling Rig photo-4
Hot Sale Trailer Mounted Water Well Drilling Rig photo-5
Hot Sale Trailer Mounted Water Well Drilling Rig photo-6
US$ 9,000 - 15,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Core Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Sanhe Hargrand Drilling Tools Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Core Drilling Rig
Power Type Diesel
Place of Origin Beijing, China
Brand Name HARGRAND
Model Number XYX-1,2,,3
Usage Other, geotechnical investigation and surveying
Voltage 220v
Power(W) 12.1kw
Dimension(L*W*H) 1640*1030*1440mm
Weight 510~560kg
Certification ISO-9001
Warranty 6months
After-sales Service Provided Engineers available to service machinery overseas

XYX-1 -2 -3 trailer mounted water well  drilling rig  Introduction(100-600meter):

XYX-1 -2 -3 trailer mounted water well drilling rig is suited for the applications of general exploration and investigation, geophysical prospecting, road and construction survey, blast holes and other drilling operations.

XYX-1 -2 -3  type:    track-mounted rig,    trailer mounted rig



Drill Rigs Features:

1.easy operation
2.lightweight to move
3.reasonable price
4.good service

Technological Data of   XYX-1 -2 -3 trailer mounted water well drilling rig:



Unity machine parameter



Drilling depth                                                                   100, 250, 300, 600m



Drilling diameter                                                               300, 200, 150, 75mm



Open hole diameter                                                                  300mm



End hole diameter                                                                     75mm



Drillng rod                                                                                 60mm



Drilling angle                                                                           90°~75 °

Rotary Spindle



Spindle forward speed                                                                                  30-1050 r/min



Spindle reverse speed                                                                                  29-137 r/min



Spindle stroke                                                                                                   560mm



Spindle inner diameter                                                                                      96mm



Spindle lifting capacity                                                                                      60KN



Main winch (drive hydraulic system)



Single line lifting speed                                                                               0-45m/min



Hug floodgate belt width                                                                             90mm



Tightrope diameter                                                                                     14mm



Hoist single line lifting capacity                                                                  40KN



Roller diameter                                                                                           200mm



Roller cubic measure                                                                                  30m



Mud pump



Horizontal triplex BW-250 mud pump



Displacement                                                                                           250 L/min



Work pressure                                                                                            7Mpa



Water inlet caliber                                                                                       75mm



Water to exit caliber                                                                                    50mm



Drill rigs Factory:





XYX-1 -2 -3 trailer mounted water well drill rig  ware house:









  XYX-3 trailer mounted water well drill rig customer:



Quality Drill rigs Manufacturer In China  -FAQ



Payment terms:100% by TT ,



Delivery time:10 days after deposit/stock







If you want to get more information,please contact me.



Name:Eric Qin



Skype id: hargrand163
