Specifications
Chinese cnc lathe 1300mmX2500mm1.CE& FDA certificate
2.Competitive price
3.Short delivery time: within 7-15 days
Chinese cnc lathe 1300mmX2500mm
Application
Drilling ,edge cutting ,engraving ,slotting ,and lock hole making and expanding for the wooden door panels, cabinet, manufacturing furniture etc.
Advantage
1.High speed: 24000r/min
2.Easy to operate
3.Working with high stable and smoothly
4.Advanced DSP system, operate with DSP handle
5 Oil lubricating system improve service life of machine
Feature :
1)This machine has Vaccum suction systerm, powerful dust exhaust apparatus to lower the human cost of fixed material,while has this machine avoiding from debris flying dust pollution.
2)Machine performance is stable,
3) Fast cutting,
4) Low cost. to use
Technical parameter
Model |
SK1325 |
Working area |
1300mmX2500mm |
X,Y movement |
Gear wheel |
XYZ repositioning accuracy |
±0.02mm |
Working model |
stepper |
Control system |
DSP |
Command language |
G code |
Interface |
USD or printer port 50 pin |
Linear guide |
Square linear guide from Taiwan |
Power |
4.5KW |
Spindle speed |
24000rpm |
Diameter of Milling cutter |
3.175,4,6,12(mm |
Power voltage |
AC380V/50-60Hz, 3-phase |
Optional device |
dust collector, Vacuum system |
Software supported |
Type3 software, wentai software |
Spare parts
Card Clamp
Spindle DSP handle
Sample display
Thanks for your visit to our website and please don't hesitate to contact us if you are interest in any.
